| Model Number | 2SD2560 |
BC848CWT1G Datasheet
Product Details
NPN Silicon
These transistors are designed for general purpose amplifier applications. They are housed in the SC−70/SOT−323 which is designed for low power surface mount applications.
• AEC−Q101 Qualified and PPAP Capable
• S Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | onsemi |
| Product Category | Transistors (BJT) - Single |
| Series | BC848CW |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.000219 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | SC-70, SOT-323 |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | SC-70-3 (SOT323) |
| Configuration | Single |
| Power-Max | 150mW |
| Transistor-Type | NPN |
| Electric current collectors | 100mA |
| Voltage-Collector-Emitter-Breakdown-Max | 30V |
| DC-Current-Gain-hFE-Min-Ic-Vce | 420 @ 2mA, 5V |
| Vce saturation | 600mV @ 5mA, 100mA |
| Current-Collector-Cutoff-Max | 15nA (ICBO) |
| Frequency-Transition | 100MHz |
| Pd-Power-Dissipation | 150 mW |
| Maximum Operating Temperature | + 150 C |
| Operating temperature range | - 55 C |
| Collector-Emitter-Voltage-VCEO-Max | 30 V |
| Transistor-Polarity | NPN |
| Collector-Emitter-Saturation-Voltage | 0.6 V |
| Collector-Base-Voltage-VCBO | 30 V |
| Emitter-Base-Voltage-VEBO | 5 V |
| Maximum-DC-Collector-Current | 0.1 A |
| Gain-Bandwidth-Product-fT | 100 MHz |
| Continuous-Collector-Current | 0.1 A |
| DC-Collector-Base-Gain-hfe-Min | 270 |
