| Place of Origin | Call |
| Brand Name | Alpha & Omega Semiconductor Inc. |
| Certification | ROHS |
| Model Number | STU85N3LH5 |
STU85N3LH5 Datasheet
Product Details
This product utilizes the 5th generation of design rules of ST’s proprietary STripFETTM technology. The lowest available RDS(on)*Qg, in the standard packages, makes this device suitable for the most demanding DC-DC converter applications, where high power density is to be achieved.
■ RDS(on) * Qg industry benchmark
■ Extremely low on-resistance RDS(on)
■ High avalanche ruggedness
■ Low gate drive power losses
Switching applications
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | FETs - Single |
| Series | N-channel STripFET |
| Packaging | Tube |
| Unit-Weight | 0.139332 oz |
| Mounting-Style | Through Hole |
| Package-Case | IPAK-3 |
| Technology | Si |
| Number-of-Channels | 1 Channel |
| Configuration | Single |
| Transistor-Type | 1 N-Channel |
| Pd-Power-Dissipation | 70 W |
| Maximum Operating Temperature | + 175 C |
| Operating temperature range | - 55 C |
| Fall-Time | 10.8 ns |
| Rise-Time | 14 ns |
| Vgs-Gate-Source-Voltage | 22 V |
| ID (drain current) | 80 A |
| Vds-Drain-Source-Breakdown-Voltage | 30 V |
| Rds-On-Drain-Source-Resistance | 5.4 mOhms |
| Transistor-Polarity | N-Channel |
| Typical-Turn-Off-Delay-Time | 23.6 ns |
| Turn-On Delay Time | 6 ns |
| Channel-Mode | Enhancement |
