| Model Number | SI7196DP-T1-E3 |
SI7196DP-T1-E3 Datasheet
Product Details
The RT8298 is a synchronous step-down DC/DC converter with an integrated high side internal power MOSFET and a gate driver for a low side external power MOSFET. It can deliver up to 6A output current from a 4.5V to 24V input supply.
4.5V to 24V Input Voltage Range
6A Output Current
45mΩInternal High Side N-MOSFET
Current Mode Control
600kHz Switching Frequency
Adjustable Output from 0.8V to 15V
Up to 95% Efficiency
Internal Compensation
Stable with Ceramic Capacitors
Synchronous External Clock : 300kHz to 1.5MHz
Cycle-by-Cycle Current Limit
Input Under Voltage Lockout
Output Under Voltage Protection
Power Good Indicator
Thermal Shutdown Protection
RoHS Compliant and Halogen Free
Point of Load Regulator in Distributed Power System
Digital Set top Boxes
Personal Digital Recorders
Broadband Communications
Flat Panel TVs and Monitors
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | VISHAY |
| Product Category | FETs - Single |
| Series | SI71xxDx |
| Packaging | Reel |
| Part-Aliases | SI7196DP-E3 |
| Unit-Weight | 0.017870 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | SO-8 |
| Technology | Si |
| Number-of-Channels | 1 Channel |
| Configuration | Single |
| Transistor-Type | 1 N-Channel |
| Pd-Power-Dissipation | 5 W |
| Maximum Operating Temperature | + 150 C |
| Operating temperature range | - 55 C |
| Fall-Time | 12 ns |
| Rise-Time | 12 ns |
| Vgs-Gate-Source-Voltage | 20 V |
| ID (drain current) | 15.8 A |
| Vds-Drain-Source-Breakdown-Voltage | 30 V |
| Rds-On-Drain-Source-Resistance | 11 mOhms |
| Transistor-Polarity | N-Channel |
| Typical-Turn-Off-Delay-Time | 22 ns |
| Turn-On Delay Time | 21 ns |
| Channel-Mode | Enhancement |
