| Model Number | AUIRFN8401TR |
AUIRFN8401TR Datasheet
Product Details
Description
Specifically designed for Automotive applications, this HEXFET® Power MOSFET utilizes the latest processing techniques to achieve extremely low on-resistance per silicon area. Additional features of this design are a 175°C junction operating temperature, fast switching speed and improved repetitive avalanche rating. These features combine to make this product an extremely efficient and reliable device for use in Automotive and wide variety of other applications.
• Advanced Process Technology
• Ultra Low On-Resistance
• 175°C Operating Temperature
• Fast Switching
• Repetitive Avalanche Allowed up to Tjmax
• Lead-Free, RoHS Compliant
• Automotive Qualified *
• Motor Control
• Reverse Battery Protection
• Heavy Loads
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | International Rectifier |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Packaging | Reel |
| Mounting-Style | SMD/SMT |
| Package-Case | PQFN-8 |
| Technology | Si |
| Number-of-Channels | 1 Channel |
| Configuration | Single |
| Transistor-Type | 1 N-Channel |
| Pd-Power-Dissipation | 4.2 W |
| Maximum Operating Temperature | + 175 C |
| Operating temperature range | - 55C |
| Fall-Time | 12 ns |
| Rise-Time | 13 ns |
| Vgs-Gate-Source-Voltage | 20 V |
| ID (drain current) | 84 A |
| Vds-Drain-Source-Breakdown-Voltage | 40 V |
| Vgs-th-Gate-Source-Threshold-Voltage | 3 V |
| Rds-On-Drain-Source-Resistance | 4.6 mOhms |
| Transistor-Polarity | N-Channel |
| Typical-Turn-Off-Delay-Time | 22 ns |
| Turn-On Delay Time | 6.1 ns |
| Qg-Gate-Charge | 44 nC |
| Transconductance | 144 S |
| Channel-Mode | Enhancement |
