| Place of Origin | Call |
| Brand Name | Integrated Circuit Systems |
| Certification | ROHS |
| Model Number | AD9578BCPZ-REEL7 |
Product Details
The AD9573 provides a highly integrated, dual output clock generator function including an on-chip PLL core that is optimized for PCI-e applications. The integer-N PLL design is based on the Analog Devices, Inc., proven portfolio of high performance, low jitter frequency synthesizers to maximize line card performance. Other applications with demanding phase noise and jitter requirements also benefit from this part.
Fully integrated VCO/PLL core
0.54 ps rms jitter from 12 kHz to 20 MHz
Input crystal frequency of 25 MHz
Preset divide ratios for 100 MHz, 33.33 MHz
LVDS/LVCMOS output format
Integrated loop filter
Space saving 4.4 mm × 5.0 mm TSSOP
0.235W power dissipation
3.3V operation
Line cards, switches, and routers
CPU/PCIe applications
Low jitter, low phase noise clock generation
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices |
| Product Category | Clock Generators and Frequency Synthesizers |
| Series | AD9578 |
| Type | * |
| Packaging | Alternate Packaging |
| Package-Case | 48-WFQFN Exposed Pad, CSP |
| Operating-Temperature | -25°C ~ 85°C |
| Mounting-Type | Surface Mount |
| Voltage-Supply | 2.375 V ~ 3.63 V |
| Supplier-Device-Package | 48-LFCSP-VQ (7x7) |
| PLL | Yes with Bypass |
| Input | LVCMOS, LVDS, LVPECL, Crystal |
| Output | HCSL, LVCMOS, LVDS, LVPECL |
| Number-of-Circuits | 1 Circuit |
| Ratio of output to input | 1899/12/30 2:05:00 |
| Differential-Input:Output | Yes/Yes |
| Frequency-Max | 919MHz |
| Divider-Multiplier | Yes/No |
Descriptions
