| Place of Origin | Call |
| Brand Name | Infineon |
| Certification | ROHS |
| Model Number | IPD90P04P4L-04 |
IPD90P04P4L-04 Datasheet
Product Details
IPD90P04P4L-04 is an OptiMOS®-P2 power-transistor.
• P-channel - Logic Level - Enhancement mode
• AEC qualified
• MSL1 up to 260°C peak reflow
• 175°C operating temperature
• Green package (RoHS compliant)
• 100% Avalanche tested
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | OptiMOS-P2 |
| Packaging | Reel |
| Part-Aliases | IPD90P04P4L04ATMA1 IPD90P04P4L04XT SP000840194 |
| Unit-Weight | 0.139332 oz |
| Mounting-Style | SMD/SMT |
| Tradename | OptiMOS |
| Package-Case | TO-252-3 |
| Technology | Si |
| Number-of-Channels | 1 Channel |
| Transistor-Type | 1 P-Channel |
| Pd-Power-Dissipation | 125 W |
| Maximum Operating Temperature | + 175 C |
| Operating temperature range | - 55 C |
| Fall-Time | 60 ns |
| Rise-Time | 20 ns |
| Vgs-Gate-Source-Voltage | 16 V |
| ID (drain current) | - 90 A |
| Vds-Drain-Source-Breakdown-Voltage | - 40 V |
| Vgs-th-Gate-Source-Threshold-Voltage | - 2.2 V |
| Rds-On-Drain-Source-Resistance | 4.3 mOhms |
| Transistor-Polarity | P-Channel |
| Typical-Turn-Off-Delay-Time | 140 ns |
| Turn-On Delay Time | 20 ns |
| Qg-Gate-Charge | 176 nC |
| Channel-Mode | Enhancement |
Descriptions
MOSFET P-Ch -40V -90A DPAK-2 OptiMOS-P2
