| Place of Origin | Call |
| Brand Name | Texas Instruments |
| Certification | ROHS |
| Model Number | TPS40050PWPR |
TPS40050PWPR DatasheetThis dual center tap Schottky rectifier is suited for switchmode power supply and high frequency DC to DC converters.
● Very small conduction losses
● Negligible switching losses
● Extremely fast switching
● Low thermal resistance
● Avalanche capability specified
● ECOPACK®2 compliant component (STPS4045CT)
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | DC DC Switching Controllers |
| Series | TPS40050 |
| Packaging | Tape & Reel (TR) Alternate Packaging |
| Unit-Weight | 0.002212 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 16-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Output-Type | Transistor Driver |
| Function | Step-Down |
| Supplier-Device-Package | 16-HTSSOP |
| Number-of-Outputs | 1 Output |
| Topology | Buck |
| Voltage-Supply-Vcc-Vdd | 8 V ~ 40 V |
| Frequency-Switching | 500kHz |
| Control-Features | Current Limit, Enable, Frequency Control, Soft Start |
| Output-Configuration | Positive |
| Output-Phases | 1 |
| Duty-Cycle-Max | 0.94 |
| Synchronous-Rectifier | Yes |
| Clock-Sync | Yes |
| Serial-Interfaces | - |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Output-Voltage | - 0.3 V to + 6 V |
| Input-Voltage | 8 V to 40 V |
| Output-Current | 200 uA |
| Package-Case | HTSSOP-16 |
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| TPS40050PWPRG4 Power Circuits |
Wide Input Voltage Synchronous Buck Controller 16-HTSSOP -40 to 85 | Texas Instruments | TPS40050PWPR vs TPS40050PWPRG4 |
| TPS40050QPWPRQ1 Power Circuits |
Automotive 8V to 40V Synchronous Buck Controller 16-HTSSOP -40 to 125 | Texas Instruments | TPS40050PWPR vs TPS40050QPWPRQ1 |
| TPS40050PWPG4 Power Circuits |
0.2A SWITCHING CONTROLLER, 1000kHz SWITCHING FREQ-MAX, PDSO16, GREEN, PLASTIC, HTSSOP-16 | Texas Instruments | TPS40050PWPR vs TPS40050PWPG4 |
| TPS40050PWP Power Circuits |
Wide Input Voltage Synchronous Buck Controller 16-HTSSOP -40 to 85 | Texas Instruments | TPS40050PWPR vs TPS40050PWP |
