| Place of Origin | Call |
| Brand Name | Texas Instruments |
| Certification | ROHS |
| Model Number | TPS3838J25QDBVRQ1 |
TPS3838J25QDBVRQ1 DatasheetThis device is a dual center tap Schottky rectifier suited for switch mode power supply and high
frequency DC to DC converters. Packaged in D2PAK, this device is especially intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications.
■ Very small conduction losses
■ Negligible switching losses
■ Extremely fast switching
■ Low thermal resistance
■ Avalanche rated
■ AEC-Q101 qualified
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Supervisors |
| Series | Automotive, AEC-Q100 |
| Type | Simple Reset/Power-On Reset |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.001058 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | SC-74A, SOT-753 |
| Operating-Temperature | -40°C ~ 125°C (TA) |
| Mounting-Type | Surface Mount |
| Output-Type | Open Collector / Drain |
| Supplier-Device-Package | SOT-23-5 |
| Output | Open Drain or Open Collector |
| Reset | Active Low |
| Voltage monitoring relays | 1 |
| Reset-Timeout | 100 ms Minimum |
| Voltage-Threshold | 2.25V |
| Pd-Power-Dissipation | 437 mW |
| Maximum Operating Temperature | + 125 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Current | 0.25 uA |
| Battery-Backup-Switching | No Backup |
| Supply-Voltage-Max | 6 V |
| Supply-Voltage-Min | 1.6 V |
| Package-Case | SOT-23-5 |
| Watchdog-Timers | No Watchdog |
| Threshold-Voltage | 2.25 V |
| Input Monitoring | 1 Input |
| Manual-Reset | Manual Reset |
| Chip-Enable-Signals | No Chip Enable |
| Power-Fail-Detection | No |
| Reset-Delay-Time | 10 ms 200 ms |
| Overvoltage-Threshold | 2.3 V |
| Undervoltage-Threshold | 2.16 V |
