| Place of Origin | Call |
| Brand Name | Texas Instruments |
| Certification | ROHS |
| Model Number | BQ24072TRGTR |
BQ24072TRGTR DatasheetDescription: The BQ24072TRGTR Texas Instruments Integrated Circuits (ICs) Battery Management is a series of battery management ICs designed to provide a constant, programmable charging current for 4.2V battery packs. It features a USB interface, a programmable current, timer, and an operating temperature range of -40°C to 125°C (TJ). The supply voltage range is 4.3V to 6.4V.
Features:
• Constant, programmable charging current
• USB interface
• Programmable current, timer
• Operating temperature range of -40°C to 125°C (TJ)
• Supply voltage range of 4.3V to 6.4V
Applications:
• Portable devices
• Wearable devices
• Battery-powered systems
• Automotive systems
• Industrial systems
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Battery Management |
| Series | BQ24072T |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.001764 oz |
| Package-Case | 16-VFQFN Exposed Pad |
| Operating-Temperature | 0°C ~ 125°C (TJ) |
| Battery-Chemistry | Lithium-Ion |
| Number-of-Cells | 1 Cell |
| Interface | USB |
| Supplier-Device-Package | 16-QFN (3x3) |
| Fault-Protection | Over Temperature, Over Voltage, Reverse Current, Short Circuit |
| Current-Charging | Constant - Programmable |
| Programmable-Features | Current, Timer |
| Electric current collectors | 1.5A |
| Battery pack | 4.2V |
| Supply Voltage | 6.4V |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Voltage | 4.3 V to 6.4 V |
| Output-Voltage | 4.2 V |
| Output-Current | 1.5 A |
| Package-Case | VQFN-16 |
| Battery-Type | Li-Ion Li-Polymer |
Form,Package,Functional compatible component
