UC3823DW DatasheetTheUC3842/3/4/5family of controlICs provides the necessary features to implement off-line or DC to DC fixed frequency current mode control schemes witha minimal external parts count.
■ OPTIMIZED FOR OFF-LINE AND DC TO DC
CONVERTERS
■ LOW START-UP CURRENT (< 1 mA)
■ AUTOMATIC FEED FORWARD COMPENSATION
■ PULSE-BY-PULSECURRENT LIMITING
■ ENHANCED LOAD RESPONSE CHARACTERISTICS
■ UNDER-VOLTAGE LOCKOUTWITH HYSTERESIS
■ DOUBLE PULSE SUPPRESSION
■ HIGH CURRENT TOTEM POLE OUTPUT
■ INTERNALLY TRIMMED BANDGAP REFERENCE
■ 500 KHz OPERATION
■ LOW RO ERRORAMP
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | AC DC Converters, Offline Switchers |
| Series | UC3823 |
| Packaging | Tube Alternate Packaging |
| Unit-Weight | 0.016709 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 16-SOIC (0.295", 7.50mm Width) |
| Operating-Temperature | 0°C ~ 70°C (TA) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | 16-SOIC |
| Watt | - |
| Number-of-Outputs | 1 Output |
| Output-Isolation | Non-Isolated |
| Internal-Switch-s | No |
| Voltage-Breakdown | - |
| Topology | Boost, Buck, Flyback, Forward |
| Voltage-Start-Up | 9.2V |
| Voltage-Supply-Vcc-Vdd | 8.4 V ~ 30 V |
| Duty-Cycle | 100% |
| Frequency-Switching | 1MHz |
| Fault-Protection | Current Limiting |
| Control-Features | Frequency Control, Soft Start |
| Maximum Operating Temperature | + 70 C |
| Operating temperature range | 0 C |
| Output-Current | 1500 mA |
| Switching-Frequency | 1000 kHz |
| Fall-Time | 30 ns |
| Rise-Time | 30 ns |
| Package-Case | SOIC-16 Wide |
| Duty-Cycle-Max | 100 % |
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| UC3823ADW Power Circuits |
High Speed PWM Controller 16-SOIC 0 to 70 | Texas Instruments | UC3823DW vs UC3823ADW |
| UC3823ADWTR Power Circuits |
High Speed PWM Controller 16-SOIC 0 to 70 | Texas Instruments | UC3823DW vs UC3823ADWTR |
| UC2823BDW Power Circuits |
High Speed PWM Controller 16-SOIC -40 to 85 | Texas Instruments | UC3823DW vs UC2823BDW |
| UC2823ADW Power Circuits |
High Speed PWM Controller 16-SOIC -40 to 85 | Texas Instruments | UC3823DW vs UC2823ADW |
| UC2823DW Power Circuits |
High Speed PWM Controller 16-SOIC -25 to 85 | Texas Instruments | UC3823DW vs UC2823DW |
| UC3823BN Power Circuits |
2.2A SWITCHING CONTROLLER, 1000kHz SWITCHING FREQ-MAX, PDIP16, DIP-16 | Rochester Electronics LLC | UC3823DW vs UC3823BN |
| UC2823ADWTR Power Circuits |
High Speed PWM Controller 16-SOIC -40 to 85 | Texas Instruments | UC3823DW vs UC2823ADWTR |
| UC3823DWTR Power Circuits |
High Speed PWM Controller 16-SOIC 0 to 70 | Texas Instruments | UC3823DW vs UC3823DWTR |
| UC2823DWTR Power Circuits |
High Speed PWM Controller 16-SOIC -25 to 85 | Texas Instruments | UC3823DW vs UC2823DWTR |
| LX1823IDW Power Circuits |
Switching Controller, Current-mode, 2A, 1500kHz Switching Freq-Max, BIPolar, PDSO16, | Linfinity Microelectronics | UC3823DW vs LX1823IDW |
