| Model Number | UC3856N |
UC3856N DatasheetSpecifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | DC DC Switching Controllers |
| Series | UC3856 |
| Packaging | Tube Alternate Packaging |
| Unit-Weight | 0.037172 oz |
| Mounting-Style | Through Hole |
| Package-Case | 16-DIP (0.300", 7.62mm) |
| Operating-Temperature | 0°C ~ 70°C (TA) |
| Output-Type | Transistor Driver |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Supplier-Device-Package | 16-PDIP |
| Number-of-Outputs | 2 Outputs |
| Topology | Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull |
| Voltage-Supply-Vcc-Vdd | 7 V ~ 40 V |
| Frequency-Switching | 200kHz |
| Control-Features | Enable, Frequency Control, Soft Start |
| Output-Configuration | Positive |
| Output-Phases | 1 |
| Duty-Cycle-Max | 0.47 |
| Synchronous-Rectifier | Yes |
| Clock-Sync | Yes |
| Serial-Interfaces | - |
| Maximum Operating Temperature | + 70 C |
| Operating temperature range | 0 C |
| Output-Current | 1500 mA |
| Switching-Frequency | 1000 kHz |
| Fall-Time | 40 ns |
| Rise-Time | 40 ns |
| Package-Case | PDIP-16 |
| Duty-Cycle-Max | 50 % |
