| Model Number | TPS40061PWP |
TPS40061PWP DatasheetThis dual center tap Schottky rectifier is suited for switchmode power supply and high frequency DC to DC converters.
● Very small conduction losses
● Negligible switching losses
● Extremely fast switching
● Low thermal resistance
● Avalanche capability specified
● ECOPACK®2 compliant component (STPS4045CT)
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | DC DC Switching Controllers |
| Series | TPS40061 |
| Packaging | Tube Alternate Packaging |
| Unit-Weight | 0.002212 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 16-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Output-Type | Transistor Driver |
| Function | Step-Down |
| Supplier-Device-Package | 16-HTSSOP |
| Number-of-Outputs | 1 Output |
| Topology | Buck |
| Voltage-Supply-Vcc-Vdd | 10 V ~ 55 V |
| Frequency-Switching | Up to 1MHz |
| Control-Features | Current Limit, Enable, Frequency Control, Soft Start |
| Output-Configuration | Positive |
| Output-Phases | 1 |
| Duty-Cycle-Max | 0.98 |
| Synchronous-Rectifier | Yes |
| Clock-Sync | Yes |
| Serial-Interfaces | - |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Output-Voltage | 0.7 V to 45 V |
| Input-Voltage | 10 V to 55 V |
| Package-Case | HTSSOP-16 |
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| TPS40061PWPRG4 Power Circuits |
Wide Input (10V-55V) up to 1 MHz Frequency Synchronous Buck Controller, source/sink 16-HTSSOP -40 to 85 | Texas Instruments | TPS40061PWP vs TPS40061PWPRG4 |
| TPS40061PWPR Power Circuits |
Wide Input (10V-55V) up to 1 MHz Frequency Synchronous Buck Controller, source/sink 16-HTSSOP -40 to 85 | Texas Instruments | TPS40061PWP vs TPS40061PWPR |
| TPS40061PWPG4 Power Circuits |
Wide Input (10V-55V) up to 1 MHz Frequency Synchronous Buck Controller, source/sink 16-HTSSOP -40 to 85 | Texas Instruments | TPS40061PWP vs TPS40061PWPG4 |
