| Model Number | ISL8702AIBZ |
ISL8702AIBZ Datasheet2A Standard Buck PWM Regulator
The ISL8500 is a high-performance, simple output controller that provides a single, high frequency power solution for a variety of point-of-load applications. The ISL8500 integrates a 2A standard buck PWM controller and switching MOSFET.
• Standard Buck Controller with Integrated Switching Power MOSFET
• Integrated Boot Diode
• Input Voltage Range
- Fixed 5V ±10%
- Variable 5.5V to 25V
• PWM Output Voltage Adjustable from 0.6V to 19V with Continuous Output Current up to 2A
• ±1% VFB Tolerance
• Voltage Mode Control with Voltage Feed Forward
• Fixed 500kHz Switching Frequency
• Externally Adjustable Soft-Start Time
• Output Undervoltage Protection
• Enable Inputs
• PGOOD Output
• Overcurrent Protection
• Thermal Overload Protection
• Internal 5V LDO regulator
• General Purpose
• WLAN Cards-PCMCIA, Cardbus32, MiniPCI Cards-Compact Flash Cards
• Hand-Held Instruments
• LCD Panel
• Set-top Box
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Renesas |
| Product Category | Supervisors |
| Series | ISL8702A |
| Type | Sequencer |
| Packaging | Tube |
| Unit-Weight | 0.011923 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 14-SOIC (0.154", 3.90mm Width) |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Mounting-Type | Surface Mount |
| Output-Type | Active Low Open Drain |
| Supplier-Device-Package | 14-SOICN |
| Output | Open Drain or Open Collector |
| Reset | Active High/Active Low |
| Voltage monitoring relays | 4 |
| Reset-Timeout | Adjustable/Selectable |
| Voltage-Threshold | Adjustable/Selectable |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Current | 191 uA |
| Battery-Backup-Switching | No Backup |
| Supply-Voltage-Max | 24 V |
| Supply-Voltage-Min | 3.3 V |
| Package-Case | SOIC-14 |
| Watchdog-Timers | No Watchdog |
| Threshold-Voltage | 3.3 V to 24 V |
| Input Monitoring | 1 Input |
| Manual-Reset | Manual Reset |
| Overvoltage-Threshold | 1.28 V |
| Undervoltage-Threshold | 1.06 V |
