ISL60007CIB825 Precision 1.25V and 2.50V, 1.08u-Watt, High Precision FGA Voltage References
  • ISL60007CIB825 Precision 1.25V and 2.50V, 1.08u-Watt, High Precision FGA Voltage References

ISL60007CIB825 Precision 1.25V and 2.50V, 1.08u-Watt, High Precision FGA Voltage References

Place of Origin Call
Brand Name Renesas
Certification ROHS
Model Number ISL60007CIB825
Product Details
Product Name:
ISL60007CIB825
Condition:
Original 100%
Installation Methodpe:
7mA Surface Mount 2.5V Series FGA™ 8-SOIC 5ppm/°C ±0.02%
Package:
8-SOIC
Voltage - Supply:
International Standard
Max. Reverse Current:
International Standard
Application:
Voltage Reference
Product Description

                                                    ISL60007CIB825 Precision 1.25V and 2.50V, 1.08u-Watt, High Precision FGA Voltage References 0ISL60007CIB825 Datasheet

Product Details

The ISL60007 FGA™ voltage references are extremely low power, very high precision analog voltage references fabricated in Intersil's proprietary Floating Gate Analog technology. The ISL60007 features low supply voltage operation at ultra-low 400nA operating current resulting in typical 1.08µW power consumption.



Features

• Reference Voltage . . . . . . . . . . . . . . . . . 1.25V, and 2.50V
• Absolute Initial Accuracy Options. . . . . ±0.5mV, & ±1.0mV
• 1.08µW typical Power Consumption
• Supply Voltage Range . . . . . . . . . . . . . . . . . . 2.7V to 5.5V
• Ultra-Low Supply Current. . . . . . . . . . . . . . . . . . . . .400nA
• Low Temperature Coefficient Options . . . . . . . . . 3ppm/°C
5ppm/°C, & 10ppm/°C
• Long Term Stability. . . . . . . . . . . . . . . . . . . 10ppm/√1kHrs
• 7mA Source & Sink Current
• ESD Protection. . . . . . . . . . . . . 5kV (Human Body Model)
• Standard 8 Ld SOIC Packaging
• Temperature Range . . . . . . . . . . . . . . . . . .-40°C to +85°C





Applications

• High Resolution A/Ds & D/As
• Digital Meters
• Bar Code Scanners
• Mobile Communications
• PDA’s and Notebooks
• Battery Management Systems
• Medical Systems

Specifications

Attribute Attribute Value
Manufacturer Renesas
Product Category Voltage Reference
Series FGA™
Packaging  Tube
Package-Case 8-SOIC (0.154", 3.90mm Width)
Operating-Temperature  -40°C ~ 85°C (TA)
Mounting-Type Surface Mount
Output-Type  Fixed
Supplier-Device-Package 8-SOIC
Tolerance  ±0.02%
Voltage-Input 2.7 V ~ 5.5 V
Current-Supply 800nA
Current-Output  7mA
Reference-Type  Series
Output Voltage  2.5V
Voltage-Output-Max -
Temperature-Coefficient  5ppm/°C
Noise-0#1Hz-to-10Hz 30μVp-p
Noise-10Hz-to-10kHz -
Current-Cathode  -

Form,Package,Functional compatible component

Descriptions

Series Voltage Reference IC ±0.02% 7mA 8-SOIC
