| Model Number | ISL6402IV |
ISL6402IV Datasheet300kHz Dual, 180° Out-of-Phase, StepDown PWM and Single Linear Controller
The ISL6402 is a high-performance, triple-output controller optimized for converting wall adapter, battery or network intermediate bus DC input supplies into the system supply voltages required for a wide variety of applications. Each output is adjustable down to 0.8V. The two PWMs are synchronized 180o out of phase reducing the RMS input current and ripple voltage.
• Wide Input Supply Voltage Range . . . . . . . . . 4.5V to 24V
• Three Independently Programmable Output Voltages
• Switching Frequency . . . . . . . . . . . . . . . . . . . . . . . 300kHz
• Out of Phase PWM Controller Operation
- Reduces Required Input Capacitance and Power Supply Induced Loads
• No External Current Sense Resistor
- Uses Lower MOSFET’s rDS(ON)
• Bidirectional Frequency Synchronization for Synchronizing Multiple ISL6402s
• Programmable Soft-Start
• Extensive circuit protection functions
- PGOOD
- UVLO
- Overcurrent
- Overtemperature
- Independent Shutdown for Both PWMs
• Excellent Dynamic Response
- Voltage Feed-Forward with Current Mode Control
• QFN Packages:
- QFN - Compliant to JEDEC PUB95 MO-220
QFN - Quad Flat No Leads - Package Outline
- Near Chip Scale Package footprint, which improves
PCB efficiency and has a thinner profile
• Pb-Free Available (RoHS Compliant)
• Power Supplies with Multiple Outputs
• xDSL Modems/Routers
• DSP, ASIC, and FPGA Power Supplies
• Set-Top Boxes
• Dual Output Supplies for DSP, Memory, Logic, µP Core and I/O
• Telecom Systems
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Renesas |
| Product Category | Voltage Regulators - Linear + Switching |
| Series | - |
| Packaging | Tube |
| Package-Case | 28-TSSOP (0.173", 4.40mm Width) |
| Operating-Temperature | -40°C ~ 85°C |
| Mounting-Type | Surface Mount |
| Function | Any Function |
| Voltage-Supply | 4.5 V ~ 24 V |
| Supplier-Device-Package | * |
| Number-of-Outputs | 3 Outputs |
| Topology | Step-Down (Buck) Synchronous (2), Linear (LDO) (1) |
| Frequency-Switching | 300kHz |
| Voltage-Current-Output-1 | Controller |
| Voltage-Current-Output-2 | Controller |
| Voltage-Current-Output-3 | Controller |
| w-LED-Driver | No |
| w-Supervisor | No |
| w-Sequencer | Yes |
