| Model Number | ISL9444CRZ-T |
HIP6012CB-T DatasheetBuck and Synchronous-Rectifier Pulse-Width Modulator (PWM) Controller
The HIP6012 provides complete control and protection for a DC-DC converter optimized for high-performance microprocessor applications. It is designed to drive two N-Channel MOSFETs in a synchronous-rectified buck topology. The HIP6012 integrates all of the control, output adjustment, monitoring and protection functions into a single package.
• Drives Two N-Channel MOSFETs
• Operates From +5V or +12V Input
• Simple Single-Loop Control Design
- Voltage-Mode PWM Control
• Fast Transient Response
- High-Bandwidth Error Amplifier
- Full 0% to 100% Duty Ratio
• Excellent Output Voltage Regulation
- 1.27V Internal Reference
- ±1.5% Over Line Voltage and Temperature
• Over-Current Fault Monitor
- Does Not Require Extra Current Sensing Element
- Uses MOSFETs rDS(ON)
• Small Converter Size
- Constant Frequency Operation
- 200kHz Free-Running Oscillator Programmable from 50kHz to Over 1MHz
• 14 Pin, SOIC Package
• Power Supply for Pentium®, Pentium Pro, PowerPC™ and Alpha™ Microprocessors
• High-Power 5V to 3.xV DC-DC Regulators
• Low-Voltage Distributed Power Supplies
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Renesas |
| Product Category | Special Purpose Voltage Regulators |
| Categories | PMIC - Voltage Regulators - Special Purpose |
| Manufacturer | Intersil |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part-Status | Obsolete |
| Applications | Controller, Intel Pentium? Pro, PowerPC, Alpha |
| Voltage-Input | 5V, 12V |
| Number-of-Outputs | 1 Output |
| Voltage-Output | 1.3 V ~ 12 V |
| Operating-Temperature | 0°C ~ 70°C |
| Mounting-Type | Surface Mount |
| Package-Case | 14-SOIC (0.154", 3.90mm Width) |
| Base-Part-Number | HIP6012 |
Form,Package,Functional compatible component
Descriptions
- Controller, Intel Pentium? Pro, PowerPC, Alpha Voltage Regulator IC 1 Output
