| Model Number | ISL6506BCBZA-T |
ISL6506BCBZA-T DatasheetThe ISL6506 complements other power building blocks (voltage regulators) in ACPI-compliant designs for microprocessor and computer applications. The IC integrates the control of the 5VDUAL and 3.3VDUAL rails into an 8 Ld EPAD SOIC package.
• Provides 2 ACPI-Controlled Voltages
- 5VDUAL USB/Keyboard/Mouse
- 3.3VDUAL/3.3VSB PCI/Auxiliary/LAN
• Excellent 3.3VDUAL Regulation in S3/S4/S5
- ±2.0% Over-Temperature
- 1A Capability on ISL6506 and ISL6506A
- 2A Capability on ISL6506B
• Small Size; Very Low External Component Count
• Over-Temperature Shutdown
• Pb-Free Available (RoHS Compliant)
• ACPI-Compliant Power Regulation for Motherboards
- ISL6506, ISL6506B: 5VDUAL is shut down in S4/S5 sleep states
- ISL6506A: 5VDUAL stays on in S4/S5 sleep states
Specifications
| ttribute | Attribute Value |
|---|---|
| Manufacturer | Renesas |
| Product Category | Power Supply Controllers, Monitors |
| Series | ISL6506B |
| Packaging | Tape & Reel (TR) Alternate Packaging |
| Mounting-Style | SMD/SMT |
| Package-Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Operating-Temperature | 0°C ~ 70°C |
| Mounting-Type | Surface Mount |
| Applications | Power Supply Controller/Monitor |
| Voltage-Supply | 4.75 V ~ 5.25 V |
| Supplier-Device-Package | 8-SOIC-EP |
| Voltage-Input | - |
| Current-Supply | 3.6mA |
| Maximum Operating Temperature | + 70 C |
| Operating temperature range | 0 C |
| Package-Case | SOIC-EP-Narrow-8 |
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| ISL6506BCB Power Circuits |
1-CHANNEL POWER SUPPLY SUPPORT CKT, PDSO8, 0.150 INCH, PLASTIC, SOIC-8 | Rochester Electronics LLC | ISL6506BCBZA-T vs ISL6506BCB |
| ISL6506BIBZ Power Circuits |
Multiple Linear Power Controller with ACPI Control Interface; SOIC8; Temp Range: -40° to 85°C | Intersil Corporation | ISL6506BCBZA-T vs ISL6506BIBZ |
| ISL6506BIBZ-T Power Circuits |
Multiple Linear Power Controller with ACPI Control Interface; SOIC8; Temp Range: -40° to 85°C | Intersil Corporation | ISL6506BCBZA-T vs ISL6506BIBZ-T |
| ISL6506BCB-T Power Circuits |
1-CHANNEL POWER SUPPLY SUPPORT CKT, PDSO8, 0.150 INCH, PLASTIC, SOIC-8 | Intersil Corporation | ISL6506BCBZA-T vs ISL6506BCB-T |
| ISL6506BCBZ-T Power Circuits |
Power Supply Support Circuit, Fixed, 1 Channel, PDSO8 | Renesas Electronics Corporation | ISL6506BCBZA-T vs ISL6506BCBZ-T |
| ISL6506BCBZ Power Circuits |
Power Supply Support Circuit | Renesas Electronics Corporation | ISL6506BCBZA-T vs ISL6506BCBZ |
| ISL6506BCBZA Power Circuits |
Power Supply Support Circuit | Renesas Electronics Corporation | ISL6506BCBZA-T vs ISL6506BCBZA |
| ISL6506BCBZA-T Power Circuits |
Power Supply Support Circuit, Fixed, 1 Channel, PDSO8 | Renesas Electronics Corporation | ISL6506BCBZA-T vs ISL6506BCBZA-T |
