UC2843AN Datasheetcurrent totem pole output ideally suited for driving a power MOSFET.
The UCX842A has UYLO thresholds of 16 V (on) and 10 V (off), ideally suited for off–line converters. The UCX843A is tailored for lower voltage applications having UVLO thresholds of 8.5 V (on) and 7.6 V (off).
• Current Mode Operation to 500 kHz
• Automatic Feed Forward Compensation
• Latching PWM for Cycle–By–Cycle Current Limiting
• Internally Trimmed Reference with Undervoltage Lockout
• High Current Totem Pole Output
• Undervoltage Lockout with Hysteresis
• Low Startup and Operating Current
• Direct Interface with Motorola SENSEFET Products
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | onsemi |
| Product Category | DC DC Switching Controllers |
| Series | UC2843A |
| Packaging | Tube |
| Unit-Weight | 0.018646 oz |
| Mounting-Style | Through Hole |
| Package-Case | 8-DIP (0.300", 7.62mm) |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Output-Type | Transistor Driver |
| Function | Step-Down |
| Supplier-Device-Package | 8-PDIP |
| Number-of-Outputs | 1 Output |
| Topology | Buck |
| Voltage-Supply-Vcc-Vdd | 8.4 V ~ 30 V |
| Frequency-Switching | 52kHz |
| Control-Features | Frequency Control |
| Output-Configuration | Positive, Isolation Capable |
| Output-Phases | 1 |
| Duty-Cycle-Max | 0.96 |
| Synchronous-Rectifier | Yes |
| Clock-Sync | No |
| Serial-Interfaces | - |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Voltage | 30 V |
| Output-Voltage | 4.95 V to 5.05 V |
| Output-Current | 1000 mA |
| Switching-Frequency | 450 kHz |
| Fall-Time | 50 ns |
| Rise-Time | 50 ns |
| Package-Case | PDIP-8 |
| Duty-Cycle-Max | 100 % |
Form,Package,Functional compatible component
Descriptions
