| Place of Origin | Call |
| Brand Name | Monolithic Power Systems |
| Certification | ROHS |
| Model Number | MP2905EK-LF-P |
MP2905EK-LF-P DatasheetThe FAN5362 is a 500mA or 705mA, step-down, switching voltage regulator that delivers a fixed output voltage from an input voltage supply of 2.7V to 5.5V. Using a proprietary architecture with synchronous rectification, the FAN5362 is capable of delivering a peak efficiency of 96%, while maintaining efficiency over 90% with load currents as low as 1mA.
This regulator transitions seamlessly into and out of 100% duty cycle operation when the supply dips to or below the regulation setpoint and smoothly recovers full regulation without overshoot when the supply recovers.
■ 3MHz Fixed-Frequency Operation
■ 45µA Typical Quiescent Current
■ 1.80 to 3.6V Fixed Output Voltage
■ 500mA or 750mA Output Current Capability
■ 2.7V to 5.5V Input Voltage Range
■ Smooth Transitions to/from 100% Duty Cycle when VIN Drops
■ PFM Mode for High Efficiency in Light Load
■ Best-in-Class Load Transient Response
■ Best-in-Class Efficiency
■ Forced PWM and External Clock Synchronization
■ Internal Soft-Start
■ Input Under-Voltage Lockout (UVLO)
■ Thermal Shutdown and Overload Protection
■ 6-Bump WLCSP, 0.4mm Pitch or 6-Lead 2 x 2mm Ultrathin Molded Leadless Package
■ SD Flash Memory Power Supply
■ RF Transeiver Power
■ Cell Phones, Smart Phones
■ Tablets, Netbooks®, Ultra-Mobile PCs
■ 3G, LTE, WiMAX™, WiBro®, and WiFi® Data Cards
■ Gaming Devices, Digital CamerasDC/DC Micro Modules
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Monolithic Power Systems |
| Product Category | DC Switching Regulators |
| Series | MP2905 |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.005051 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Operating-Temperature | -20°C ~ 85°C (TA) |
| Mounting-Type | Surface Mount |
| Output-Type | Adjustable |
| Function | Step-Down |
| Supplier-Device-Package | 10-MSOP |
| Number-of-Outputs | 1 Output |
| Topology | Buck |
| Frequency-Switching | 200kHz ~ 500kHz |
| Current-Output | - |
| Output-Configuration | Positive |
| Output Voltage | 0.6V |
| Voltage-Output-Max | 25.2V |
| Synchronous-Rectifier | Yes |
| Voltage-Input-Min | 3V |
| Voltage-Input-Max | 28V |
| Maximum Operating Temperature | + 125 C |
| Operating temperature range | - 40 C |
| Output-Voltage | 600 mV to 25.2 V |
| Switching-Frequency | 200 kHz to 500 kHz |
| Package-Case | MSOP-10 |
Form,Package,Functional compatible component
