| Model Number | AUIRS2336S |
ITS4140NHUMA1 Datasheet• N channel vertical power MOSFET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in Smart SIPMOS technology.
• Providing embedded protective functions
• µC compatible high-side power switch with diagnostic feedback for 5V, 12V and 24V grounded loads in industrial applications
• All types of resistive, inductive and capacitve loads
• Most suitable for loads with high inrush currents, so as lamps
• Replaces electromechanical relays, fuses and discrete circuits
• Very low standby current
• CMOS compatible input
• Improved electromagnetic compatibility (EMC)
• Fast demagnetization of inductive loads
• Stable behaviour at undervoltage
• Wide operating voltage range
• Logic ground independent from load ground
• Short circuit protection
• Overload protection
• Current limitation
• Thermal shutdown
• Overvoltage protection (including load dump) with external resistor
• Reverse battery protection with external resistor
• Loss of ground and loss of Vbb protection
• Electrostatic discharge protection (ESD)
• Diagnostic feedback with open drain output
• Open load detection in ON-state
• Feedback of thermal shutdown in ON-state
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon |
| Product Category | Power Distribution Switches, Load Drivers |
| Mfr | Infineon Technologies |
| Series | - |
| Package | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® |
| Product-Status | Active |
| Switch-Type | General Purpose |
| Number-of-Outputs | 1 |
| Ratio-Input | Output |
| Output-Configuration | High Side |
| Output-Type | N-Channel |
| Interface | On/Off |
| Voltage-Load | 4．9V ~ 60V |
| Voltage-Supply-Vcc-Vdd | Not Required |
| Current-Output-Max | 200mA |
| Rds-On-Typ | 1Ohm |
| Input-Type | Non-Inverting |
| Features | Auto Restart |
| Fault-Protection | Current Limiting (Fixed) Over Temperature Over Voltage |
| Operating-Temperature | -30°C ~ 85°C (TA) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | PG-SOT223-4 |
| Package-Case | TO-261-4 TO-261AA |
| Base-Product-Number | ITS4140 |
