| Place of Origin | Call |
| Brand Name | STMicroelectronics |
| Certification | ROHS |
| Model Number | TSM112CN |
TSM112CN DatasheetThe TSM112 integrated circuit incorporates all sensing circuitry to regulate and protect from over voltage and under voltage a multiple output power supply (3.3V, 5V and 12V).
■ UNDER VOLTAGE PROTECTION FOR 3.3V 5V AND 12V WITHOUT EXTERNAL COMPONENTS
■ OVER VOLTAGE PROTECTION FOR -12V OR -5V WITH EXTERNAL COMPONENTS
■ EXTERNALLY ADJUSTABLE UNDER VOLTAGE BLANKING DURING POWER UP
■ POWER GOOD INPUT/OUTPUT
■ EXTERNALLY ADJUSTABLE PG DELAY
■ FAULT OUTPUT
■ REMOTE OUTPUT
■ EXTERNALLY ADJUSTABLE REMOTE DELAY
■ PRECISION VOLTAGE REFERENCE
■ 2kV ESD PROTECTION
■ PC SMPS Triple Power Line Housekeeping IC (3.3V 5V 12V)
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | IC Chips |
| Series | - |
| Type | Multi-Voltage Supervisor |
| Packaging | Tube |
| Package-Case | 14-DIP (0.300", 7.62mm) |
| Operating-Temperature | 0°C ~ 70°C (TA) |
| Mounting-Type | Through Hole |
| Supplier-Device-Package | 14-DIP |
| Output | - |
| Reset | - |
| Voltage monitoring relays | 3 |
| Reset-Timeout | 100 ms Minimum |
| Voltage-Threshold | 4V, 6.1V, 14.2V |
Form,Package,Functional compatible component
Descriptions
Supervisor 3 Channel 14-DIP
