EP4CGX30CF23C7N FPGA - Field Programmable Gate Array
  • EP4CGX30CF23C7N FPGA - Field Programmable Gate Array
EP4CGX30CF23C7N FPGA - Field Programmable Gate Array

EP4CGX30CF23C7N FPGA - Field Programmable Gate Array

Place of Origin Call
Brand Name Intel / Altera
Certification ROHS
Model Number EP4CGX30CF23C7N
Product Details
Product Name:
EP4CGX30CF23C7N
Condition:
Original 100%
Installation Methodpe:
FPGA 290 I/O Surface Mount 290 I/O 0°C ~ 85°C (TJ) 484-BGA Cyclone® IV GX 1105920 Bits 1.16 V ~ 1.24 V
Package:
484-BGA
Voltage - Supply:
International Standard
Max. Reverse Current:
International Standard
Application:
FPGAs (Field Programmable Gate Array)
Product Description

                                                         EP4CGX30CF23C7N FPGA - Field Programmable Gate Array 0EP4CGX30CF23C7N Datasheet

Product Details

Altera’s new Cyclone® IV FPGA device family extends the Cyclone FPGA series leadership in providing the market’s lowest-cost, lowest-power FPGAs, now with a transceiver variant. Cyclone IV devices are targeted to high-volume, cost-sensitive applications, enabling system designers to meet increasing bandwidth requirements while lowering costs.

Cyclone IV Device Family Features

The Cyclone IV device family offers the following features:
■ Low-cost, low-power FPGA fabric:
■ 6K to 150K logic elements
■ Up to 6.3 Mb of embedded memory
■ Up to 360 18 × 18 multipliers for DSP processing intensive applications
■ Protocol bridging applications for under 1.5 W total power
■ Cyclone IV GX devices offer up to eight high-speed transceivers that provide:
■ Data rates up to 3.125 Gbps
■ 8B/10B encoder/decoder
■ 8-bit or 10-bit physical media attachment (PMA) to physical coding sublayer (PCS) interface
■ Byte serializer/deserializer (SERDES)
■ Word aligner
■ Rate matching FIFO
■ TX bit slipper for Common Public Radio Interface (CPRI)
■ Electrical idle
■ Dynamic channel reconfiguration allowing you to change data rates andprotocols on-the-fly
■ Static equalization and pre-emphasis for superior signal integrity
■ 150 mW per channel power consumption
■ Flexible clocking structure to support multiple protocols in a single transceiver block
■ Cyclone IV GX devices offer dedicated hard IP for PCI Express (PIPE) (PCIe) Gen 1:
■ ×1, ×2, and ×4 lane configurations
■ End-point and root-port configurations
■ Up to 256-byte payload
■ One virtual channel
■ 2 KB retry buffer
■ 4 KB receiver (Rx) buffer
■ Cyclone IV GX devices offer a wide range of protocol support:
■ PCIe (PIPE) Gen 1 ×1, ×2, and ×4 (2.5 Gbps)
■ Gigabit Ethernet (1.25 Gbps)
■ CPRI (up to 3.072 Gbps)
■ XAUI (3.125 Gbps)
■ Triple rate serial digital interface (SDI) (up to 2.97 Gbps)
■ Serial RapidIO (3.125 Gbps)
■ Basic mode (up to 3.125 Gbps)
■ V-by-One (up to 3.0 Gbps)
■ DisplayPort (2.7 Gbps)
■ Serial Advanced Technology Attachment (SATA) (up to 3.0 Gbps)
■ OBSAI (up to 3.072 Gbps)
■ Up to 532 user I/Os
■ LVDS interfaces up to 840 Mbps transmitter (Tx), 875 Mbps Rx
■ Support for DDR2 SDRAM interfaces up to 200 MHz
■ Support for QDRII SRAM and DDR SDRAM up to 167 MHz
■ Up to eight phase-locked loops (PLLs) per device
■ Offered in commercial and industrial temperature grades

Specifications

Attribute Attribute Value
Manufacturer Intel / Altera
Product Category FPGAs (Field Programmable Gate Array)
Series Cyclone® IV GX
Product Cyclone IV GX
Packaging  Tray
Mounting-Style SMD/SMT
Tradename Cyclone IV
Package-Case 484-BGA
Operating-Temperature  0°C ~ 85°C (TJ)
Mounting-Type Surface Mount
Voltage-Supply 1.16 V ~ 1.24 V
Supplier-Device-Package 484-FBGA (23x23)
IC Number of Gates  -
Number-of-I-O 290 I/O
Data-Rate  3.125 Gbps
Number-of-LABs-CLBs 1840
Number-of-Logic-Elements-Cells  29440
Total-RAM-Bits  1105920 Bits
Maximum Operating Temperature  + 70 C
Operating temperature range 0 C
Operating-Supply-Voltage 1 V to 1.2 V
Maximum-Operating-Frequency  200 MHz
Package-Case FBGA-484
Number-of-Transceivers 4 Transceivers
Input/output  290 I/O
Number-of-Logic-Array-Blocks-LABs 1840
Number-of-Logic-Elements 29440 Logic Elements
Total-Memory  1080 kbit

Form,Package,Functional compatible component



Manufacturer Part# Description Manufacturer Compare
EP4CGX30CF23C6N
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, LEAD FREE, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C6N
EP4CGX30CF23C7N
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, LEAD FREE, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C7N
EP4CGX30CF23I7
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23I7
EP4CGX30CF23I7N
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, LEAD FREE, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23I7N
EP4CGX30CF23C7
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C7
EP4CGX30CF23C6
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C6
EP4CGX30CF23C8N
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, LEAD FREE, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C8N
EP4CGX30CF23C8
Programmable Logic		 Field Programmable Gate Array, 1840 CLBs, 472.5MHz, 29440-Cell, PBGA484, 23 X 23 MM, 1 MM PITCH, FBGA-484 Intel Corporation EP4CGX30CF23C7N vs EP4CGX30CF23C8


Descriptions

IC FPGA 290 I/O 484FBGA
FPGA Cyclone庐 IV GX Family 29440 Cells 60nm Technology 1.2V 484-Pin FBGA
