| Model Number | SN74AUP1G00DRLR |
SN74AUP1G00DRLR DatasheetThese data selectors/multiplexers contain inverters and drivers to supply full data selection to the four output gates. A separate strobe (G) input is provided. A 4-bit word is selected from one of two sources and is routed to the four outputs. The ′ALS157A and SN74AS157 present true data. The ′ALS158 and SN74AS158 present inverted data to minimize propagation delay time.
• Package Options Include Plastic Small-Outline (D) Packages, Ceramic Chip Carriers (FK), and Standard Plastic (N) and Ceramic (J) 300-mil DIPs
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Gates and Inverters |
| Series | 74AUP |
| Product | Single-Function Gate |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.000099 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | SOT-553 |
| Operating-Temperature | -40°C ~ 85°C |
| Mounting-Type | Surface Mount |
| Features | - |
| Voltage-Supply | 0.8 V ~ 3.6 V |
| Supplier-Device-Package | SOT-5 |
| Number-of-Circuits | 1 Circuit |
| IC Number of Gates | 1 Gate |
| Number-of-Inputs | 2 Inputs |
| Quiescent Current | 0.5μA |
| Current-Output-High-Low | 4mA, 4mA |
| Max-Propagation-Delay-V-Max-CL | 6.5ns @ 3.3V, 30pF |
| Logic-Type | NAND Gate |
| Logic-Level-Low | 0.7 V ~ 0.9 V |
| Logic-Level-High | 1.6 V ~ 2 V |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Supply-Voltage-Max | 3.6 V |
| Supply-Voltage-Min | 0.8 V |
| Package-Case | SOT-553-5 |
| Logic-Family | 74AUP |
| Propagation Delay | 21.9 ns |
| High-Level-Output-Current | - 4 mA |
| Low-Level-Output-Current | 4 mA |
| Number-of-Input-Lines | 2 Input |
| Number-of-Output-Lines | 1 Output |
| Logic-Function | NAND |
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| SN74AUP1G00DRLRG4 Logic |
Low-Power Single Two-Input Positive-NAND Gate 5-SOT-5X3 -40 to 85 | Texas Instruments | SN74AUP1G00DRLR vs SN74AUP1G00DRLRG4 |
