Specifications
Attribute | Attribute Value |
---|---|
Manufacturer | Texas Instruments |
Product Category | Voltage Translators, Level Shifters |
Series | 74AVC |
Packaging | Tube Alternate Packaging |
Unit-Weight | 0.003157 oz |
Mounting-Style | SMD/SMT |
Package-Case | 24-TSSOP (0.173", 4.40mm Width) |
Operating-Temperature | -40°C ~ 85°C (TA) |
Mounting-Type | Surface Mount |
Output-Type | Tri-State, Non-Inverted |
Features | - |
Supplier-Device-Package | 24-TSSOP |
Number-of-Circuits | 1 Circuit |
Data-Rate | 320Mbps |
Logic-Type | CMOS |
Translator-Type | Voltage Level |
Channel-Type | Bidirectional |
Channels-per-Circuit | 8 |
Voltage-VCCA | 1.2 V ~ 3.6 V |
Voltage-VCCB | 1.2 V ~ 3.6 V |
Input-Signal | - |
Output-Signal | - |
Maximum Operating Temperature | + 85 C |
Operating temperature range | - 40 C |
Supply-Voltage-Max | 3.6 V |
Supply-Voltage-Min | 1.2 V |
Package-Case | TSSOP-24 |
Logic-Family | 74AVC |
Propagation Delay | 2.5 ns |
Form,Package,Functional compatible component
Manufacturer Part# | Description | Manufacturer | Compare |
SN74AVC8T245RGYR Logic |
AVC SERIES, OCTAL 1-BIT TRANSCEIVER, TRUE OUTPUT, PQCC24, QFN-24 | Rochester Electronics LLC | SN74AVC8T245PWR vs SN74AVC8T245RGYR |
SN74AVC8T245PWRG4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TSSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245PWRG4 |
74AVC8T245RHLRG4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-VQFN -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs 74AVC8T245RHLRG4 |
SN74AVC8T245DGVR Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TVSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245DGVR |
SN74AVC8T245PW Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TSSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245PW |
SN74AVC8T245PWE4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TSSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245PWE4 |
74AVC8T245DGVRE4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TVSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs 74AVC8T245DGVRE4 |
SN74AVC8T245RHLR Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-VQFN -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245RHLR |
SN74AVC8T245PWG4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TSSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245PWG4 |
SN74AVC8T245PWRE4 Logic |
8-Bit Dual-Supply Bus Transceiver with Configurable Voltage-Level Shifting and 3-State Outputs 24-TSSOP -40 to 125 | Texas Instruments | SN74AVC8T245PWR vs SN74AVC8T245PWRE4 |
