MCR8SMG Datasheet
Product Details
SCRs 8 AMPERES RMS 400 thru 800 VOLTS
Designed primarily for half-wave ac control applications, such as motor controls, heating controls, and power supplies; or wherever half−wave, silicon gate−controlled devices are needed.
• Sensitive Gate Allows Triggering by Microcontrollers and other Logic Circuits
• Blocking Voltage to 800 Volts
• On−State Current Rating of 8 Amperes RMS at 80°C
• High Surge Current Capability − 80 Amperes
• Rugged, Economical TO−220AB Package
• Glass Passivated Junctions for Reliability and Uniformity
• Minimum and Maximum Values of IGT, VGT and IH Specified for Ease of Design
• Immunity to dv/dt − 5 V/sec Minimum at 110°C
• Pb−Free Packages are Available*
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | onsemi |
| Product Category | SCRs |
| Series | MCR8SM |
| Packaging | Tube |
| Unit-Weight | 0.211644 oz |
| Mounting-Style | Through Hole |
| Package-Case | TO-220-3 |
| Operating-Temperature | -40°C ~ 110°C |
| Mounting-Type | Through Hole |
| Supplier-Device-Package | TO-220AB |
| Holding Current | 6mA |
| Voltage-Off-State | 600V |
| Voltage-Gate-Trigger-Vgt-Max | 1V |
| Current-Gate-Trigger-Igt-Max | 200μA |
| Voltage-On-State-Vtm-Max | 1.8V |
| Current-On-State-It-AV-Max | - |
| Current-On-State-It-RMS-Max | 8A |
| Off-State Current | 10μA |
| Current-Non-Rep#-Surge-50-60Hz-Itsm | 80A @ 60Hz |
| SCR-Type | Sensitive Gate |
| Maximum Operating Temperature | + 110 C |
| Operating temperature range | - 40 C |
| Rated-Repetitive-Off-State-Voltage-VDRM | 600 V |
| Holding-Current-Ih-Max | 6 mA |
| Gate-Trigger-Voltage-Vgt | 1 V |
| Gate-Trigger-Current-Igt | 0.2 mA |
| IT(RMS) On-state rms current | 8 A |
| Non-Repetitive-On-State-Current | 80 A |
| Off-State-Leakage-Current-VDRM-IDRM | 0.01 mA |
| Vf-Forward-Voltage | 1.8 V |
