| Place of Origin | Call |
| Brand Name | TOSHIBA |
| Certification | ROHS |
| Model Number | 2SK2504TL |
2SK2504TL Datasheet
Product Details
1) Low On-resistance.
2) Fast switching speed.
3) Wide SOA (safe operating area).
4) 4V drive.
5) Drive circuits can be simple.
6) Parallel use is easy.
Switching
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | ROHM |
| Product Category | FETs - Single |
| Categories | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Cut Tape (CT) |
| Part-Status | Obsolete |
| FET-Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain-to-Source-Voltage-Vdss | 100V |
| Current-Continuous-Drain-Id-25°C | 5A (Ta) |
| Drive-Voltage-Max-Rds-On-Min-Rds-On | 4V, 10V |
| Vgs-th-Max-Id | 2.5V @ 1mA |
| Vgs-Max | ±20V |
| Input-Capacitance-Ciss-Max-Vds | 520pF @ 10V |
| FET-Feature | - |
| Power-Dissipation-Max | 20W (Tc) |
| Rds-On-Max-Id-Vgs | 220 mOhm @ 2.5A, 10V |
| Operating-Temperature | 150°C (TJ) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | CPT3 |
| Package-Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
Descriptions
N-Channel 100V 5A (Ta) 20W (Tc) Surface Mount CPT3
