| Place of Origin | Call |
| Brand Name | Analog Devices |
| Certification | ROHS |
| Model Number | ADG451BN |
ADG451BN Datasheet
Product Details
The ADG451BN is a monolithic analog switch IC containing four independently switchable switches for video signal switching. The ADG451BN combines low power dissipation and high switching speed over the temperature range of -40°C to 85°C. The analog switch IC also has excellent linearity and low distortion, and it has a minimum supply voltage of 5V.
· Low on resistance (4 Ω)
· On resistance flatness (0.2 Ω)
· 44 V supply maximum ratings
· ±15 V analog signal range
· Fully specified at ±5 V, 12 V, ±15 V
· Ultralow power dissipation (18 μW)
· ESD 2 kV
· Continuous current (100 mA)
· Fast switching times
· tON 70 ns
· tOFF 60 ns
· TTL-/CMOS-compatible
· Pin-compatible upgrade for ADG411/ADG412/ADG413 and ADG431/ADG432/ADG433
· Relay replacement
· Audio and video switching
· Automatic test equipment
· Precision data acquisition
· Battery-powered systems
· Sample-and-hold systems
· Communication systems
· PBX, PABX systems
· Avionics
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices |
| Product Category | Analog Switches, Multiplexers, Demultiplexers |
| Categories | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part-Status | Obsolete |
| Switch-Circuit | SPST - NC |
| Multiplexer-Demultiplexer-Circuit | 1 |
| Number-of-Circuits | 4 Circuits |
| On-State-Resistance-Max | 5 Ohm |
| Channel-to-Channel-Matching-ΔRon | 100 mOhm |
| Voltage-Supply-Single-V+ | 12V |
| Voltage-Supply-Dual-V± | ±4.5 V ~ 20 V |
| Switch-Time-Ton-Toff-Max | 180ns, 140ns |
| -3db-Bandwidth | - |
| Charge-Injection | 20pC |
| Channel-Capacitance-CS-off-CD-off | 37pF, 37pF |
| Current-Leakage-IS-off-Max | 500pA |
| Crosstalk | -90dB @ 1MHz |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Package-Case | 16-DIP (0.300", 7.62mm) |
| Supplier-Device-Package | 16-PDIP |
| Base-Part-Number | ADG451 |
Descriptions
4 Circuit IC Switch 1:1 5 Ohm 16-PDIP
