| Place of Origin | Call |
| Brand Name | Infineon |
| Certification | ROHS |
| Model Number | AUIPS7221RTRL |
Product Details
The AUIPS7142G is a fully protected dual high side switch specifically designed for driving lamp. It features current sensing, over-current, over-temperature, ESD protection and drain to source active clamp. The Ifb pin is used for current sensing. The over-current shutdown is higher than inrush current of the lamp.
• 24V battery system
• Over current shutdown
• Over temperature shutdown
• Current sensing
• Active clamp
• Low quiescent current
• ESD protection
• Optimized Turn On/Off for EMI
• Lead free and RoHS compliant
• 21W Filament lamp
• Solenoid
• 24V truck loads
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon |
| Product Category | Power Distribution Switches, Load Drivers |
| Series | Automotive, AEC-Q100 |
| Product | Half-Bridge Drivers |
| Type | High Side |
| Packaging | Reel |
| Mounting-Style | SMD/SMT |
| Package-Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
| Input-Type | Non-Inverting |
| Operating-Temperature | -40°C ~ 150°C (TJ) |
| Output-Type | N-Channel |
| Features | - |
| Interface | On/Off |
| Supplier-Device-Package | D-Pak |
| Ratio of output to input | 1899/12/30 1:01:00 |
| Number-of-Outputs | 1 Output |
| Voltage-Supply-Vcc-Vdd | - |
| Fault-Protection | Current Limiting (Fixed), Over Temperature |
| Output-Configuration | High Side |
| Rds-On-Typ | 30 mOhm |
| Voltage-Load | 6 V ~ 60 V |
| Current-Output-Max | - |
| Switch-Type | General Purpose |
| Pd-Power-Dissipation | 2.5 W |
| Maximum Operating Temperature | + 150 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Current | 200 nA |
| Output-Current | 200 nA |
| Fall-Time | 0.1 us |
| Rise-Time | 0.3 us |
| Supply-Voltage-Max | 5.5 V |
| Supply-Voltage-Min | 0.9 V |
| Package-Case | DPAK-5 |
| Number-of-Drivers | 1 Driver |
| Maximum-Turn-Off-Delay-Time | 1.2 us |
| Turn-On Delay Time | 0.9 us |
