| Model Number | SM6S15AHE3/2D |
Product Details
[ST-Microelectronics]
The SMBJ series are TRANSILTM diodes designed specifically for protecting sensitive equipment against transient overvoltages.
Transil diodes provide high overvoltage protection by clamping action. Their instantaneous response to transient overvoltages makes them particularly suited to protect voltage sensitive devices such as MOS Technology and low voltage supplied IC’s.
■ PEAK PULSE POWER : 600 W (10/1000µs)
■ STAND OFF VOLTAGE RANGE : From 5V to 188V.
■ UNI AND BIDIRECTIONAL TYPES
■ LOW CLAMPING FACTOR
■ FAST RESPONSE TIME
■ JEDEC REGISTERED PACKAGE OUTLINE
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | TVS Diodes |
| Series | SMBJ, TRANSIL™ |
| Type | Zener |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.003880 oz |
| Mounting-Style | SMD/SMT |
| Termination-Style | SMD/SMT |
| Tradename | Transil |
| Operating-Temperature-Range | - 65 C to + 175 C |
| Height | 2.45 mm |
| Length | 4.6 mm |
| Width | 3.95 mm |
| Package-Case | DO-214AA, SMB |
| Operating-Temperature | -55°C ~ 150°C (TJ) |
| Mounting-Type | Surface Mount |
| Applications | General Purpose |
| Supplier-Device-Package | SMB (DO-214AA) |
| Unidirectional-Channels | 1 |
| Bidirectional-Channels | |
| Voltage-Reverse-Standoff-Typ | 70V |
| Breakdown Voltage | 77.8V |
| Clamping Voltage | 146V |
| Current-Peak-Pulse-10-1000μs | 27A (8/20μs) |
| Power-Peak-Pulse | 600W |
| Power-Line-Protection | No |
| Capacitance-Frequency | - |
| Pd-Power-Dissipation | 400 W |
| Maximum Operating Temperature | + 150 C |
| Operating temperature range | - 55 C |
| Breakdown-Voltage | 81.9 V |
| Clamping-Voltage | 146 V |
| Peak-Surge-Current | 5.5 A |
| Working-Voltage | 70 V |
| Polarity | Unidirectional |
