| Place of Origin | Call |
| Brand Name | Analog Devices / Linear Technology |
| Certification | ROHS |
| Model Number | LTC2908IDDB-B1#TRPBF |
LTC2908IDDB-B1#TRPBF Datasheet
Product Details
The LTC®2908 is a six input supply monitor for systems requiring a precise and compact monitoring solution for multiple supply voltages. The inputs can be shorted together for monitoring systems with fewer than six supply voltages, and the open drain RST output of two or more LTC2908s can be wired-OR together for monitoring systems with more than six supply voltages. The common reset output remains low until all six inputs have been in compliance for 200ms.
■ Ultralow Voltage Reset: VCC = 0.5V Guaranteed*
■ Monitors Six Inputs Simultaneously:
5V, 3.3V, 2.5V, 1.8V, ADJ1, ADJ2 (LTC2908-A1)
3.3V, 2.5V, 1.8V, 1.5V, ADJ1, ADJ2 (LTC2908-B1)
2.5V, ADJ1, ADJ2, ADJ3, ADJ4, ADJ5 (LTC2908-C1)
■ Guaranteed Threshold Accuracy: ±1.5% of Monitored Voltage Overtemperature
■ Internal VCC Auto Select
■ Power Supply Glitch Immunity
■ 200ms Reset Time Delay
■ Active Low Open-Drain RST Output
■ Low Profi le (1mm) 8-Lead SOT-23 (ThinSOT™) and Plastic (3mm × 2mm) DFN Packages
■ Network Servers
■ Wireless Base Stations
■ Optical Networking Systems
■ Multivoltage Systems
■ Desktop and Notebook Computers
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices / Linear Technology |
| Product Category | Supervisors |
| Series | - |
| Type | Multi-Voltage Supervisor |
| Packaging | Tape & Reel (TR) Alternate Packaging |
| Package-Case | 8-WFDFN Exposed Pad |
| Operating-Temperature | -40°C ~ 85°C (TA) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | 8-DFN (3x2) |
| Output | Open Drain or Open Collector |
| Reset | Active Low |
| Voltage monitoring relays | 6 |
| Reset-Timeout | 160 ms Minimum |
| Voltage-Threshold | 1.403V, 1.683V, 2.338V, 3.086V, Adj, Adj |
