Semiconductor ICs
>
|
| Place of Origin | Call |
| Brand Name | Maxim Integrated |
| Certification | ROHS |
| Model Number | MAX253EUA+T |
Product Details
The MAX253 is a monolithic oscillator/power-driver, specifically designed to provide isolated power for an isolated RS-485 or RS-232 data interface. It drives a center-tapped transformer primary from a 5V or 3.3V DC power supply. The secondary can be wound to provide any isolated voltage needed at power levels up to 1W.
♦ Power-Supply Transformer Driver for Isolated RS-485/RS-232 Data-Interface Applications
♦ Single +5V or +3.3V Supply
♦ Low-Current Shutdown Mode: 0.4µA
♦ Pin-Selectable Frequency: 350kHz or 200kHz
♦ 8-Pin DIP, SO, and µMAX Packages
Isolated RS-485/RS-232 Power-Supply Transformer Driver
High Noise-Immunity Communications Interface
Isolated and/or High-Voltage Power Supplies
Bridge Ground Differentials
Medical Equipment
Process Control
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Maxim Integrated |
| Product Category | Specialized Power Management IC |
| Series | MAX253 |
| Product | Half-Bridge Drivers |
| Type | Non-Inverting |
| Packaging | Tape & Reel (TR) Alternate Packaging |
| Mounting-Style | SMD/SMT |
| Package-Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Operating-Temperature | -40°C ~ 85°C |
| Mounting-Type | Surface Mount |
| Applications | Transformer Driver |
| Voltage-Supply | 3.3V, 5V |
| Supplier-Device-Package | 8-uMAX |
| Current-Supply | 450μA |
| Pd-Power-Dissipation | 727 mW |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Current | 450 uA |
| Output-Current | 1 A |
| Part-#-Aliases | MAX253 |
| Supply-Voltage-Max | 6 V |
| Supply-Voltage-Min | 2.5 V |
| Number-of-Drivers | 1 Driver |
