LM2575T-15/NOPB Switching Voltage Regulators 1A STEP-DOWN VLTG REG
  • LM2575T-15/NOPB Switching Voltage Regulators 1A STEP-DOWN VLTG REG

LM2575T-15/NOPB Switching Voltage Regulators 1A STEP-DOWN VLTG REG

Place of Origin Call
Brand Name Texas Instruments
Certification ROHS
Model Number LM2575T-15/NOPB
Product Details
Product Name:
LM2575T-15/NOPB
Condition:
Original 100%
Installation Methodpe:
DC DC Switching Regulator 1A 52kHz Step-Down Through Hole 15V Fixed TO-220-5 Buck
Package:
TO-220-5
Voltage - Supply:
International Standard
Max. Reverse Current:
International Standard
Application:
DC Switching Regulators
Product Description

                                                                  LM2575T-15/NOPB Switching Voltage Regulators 1A STEP-DOWN VLTG REG 0LM2575T-15/NOPB Datasheet

Product Details

Specifications

Attribute Attribute Value
Manufacturer Texas Instruments
Product Category DC Switching Regulators
Series SIMPLE SWITCHER®
Type Inverting Step Down
Packaging  Tube
Unit-Weight  0.068079 oz
Mounting-Style Through Hole
Tradename Simple Switcher
Operating-Temperature-Range  - 40 C to + 85 C
Package-Case TO-220-5
Operating-Temperature  -40°C ~ 125°C (TJ)
Mounting-Type Through Hole
Output-Type Fixed
Function Step-Down
Supplier-Device-Package TO-220-5
Number-of-Outputs 1 Output
Topology Buck
Frequency-Switching  52kHz
Current-Output  1A
Output-Configuration Positive
Output Voltage  15V
Voltage-Output-Max -
Synchronous-Rectifier  No
Voltage-Input-Min 4V
Voltage-Input-Max  40V
Maximum Operating Temperature  + 125 C
Operating temperature range - 40 C
Output-Voltage  15 V
Input-Voltage-MAX 40 V
Output-Current  1 A
Switching-Frequency  58 kHz
Input-Voltage-MIN  4 V
Package-Case TO-220-5

Descriptions

Buck Switching Regulator IC Positive Fixed 15V 1 Output 1A TO-220-5
Conv DC-DC 4V to 40V Step Down Single-Out 15V 1A 5-Pin(5+Tab) TO-220 Tube
Voltage Regulators - Switching Regulators 1A STEP-DOWN VLTG REG
