UC2854ADW Power Factor Correction - PFC Enhanced High Power Factor Preregulator
  • UC2854ADW Power Factor Correction - PFC Enhanced High Power Factor Preregulator
  • UC2854ADW Power Factor Correction - PFC Enhanced High Power Factor Preregulator

UC2854ADW Power Factor Correction - PFC Enhanced High Power Factor Preregulator

Place of Origin Call
Brand Name Texas Instruments
Certification ROHS
Model Number UC2854ADW
Product Details
Product Name:
UC2854ADW
Condition:
Original 100%
Installation Methodpe:
PFC 250μA 200kHz Average Current Surface Mount -40°C ~ 85°C 16-SOIC 10 V ~ 20 V
Package:
16-SOIC (0.295", 7.50mm Width)
Voltage - Supply:
International Standard
Max. Reverse Current:
International Standard
Application:
PFC (Power Factor Correction)
Product Description

                                                                  UC2854ADW Power Factor Correction - PFC Enhanced High Power Factor Preregulator 0UC2854ADW Datasheet

Product Details

Description: The UC2854ADW is a Power Factor Correction (PFC) integrated circuit from Texas Instruments. It is designed to provide a high-performance, cost-effective solution for power factor correction applications. It features a wide operating voltage range of 10 V to 20 V, a switching frequency of 200 kHz, and a low startup current of 250 μA. The device is housed in a 16-SOIC package and is suitable for surface mount applications.

Features:
• Wide operating voltage range of 10 V to 20 V
• Switching frequency of 200 kHz
• Low startup current of 250 μA
• 16-SOIC package
• Suitable for surface mount applications

Applications:
The UC2854ADW is suitable for a variety of power factor correction applications, including LED lighting, motor drives, and power supplies. It is also suitable for use in automotive, industrial, and consumer applications.



Specifications

Attribute Attribute Value
Manufacturer Texas Instruments
Product Category PFC (Power Factor Correction)
Series -
Packaging  Tube Alternate Packaging
Package-Case 16-SOIC (0.295", 7.50mm Width)
Operating-Temperature  -40°C ~ 85°C
Mounting-Type Surface Mount
Voltage-Supply  10 V ~ 20 V
Supplier-Device-Package 16-SOIC
Frequency-Switching  200kHz
Mode Average Current
Current-Startup 250μA



Descriptions

PFC IC Average Current 200kHz 16-SOIC
PREREGUL 0.3mA 115kHz 16-Pin SOIC Tube
Power Factor Correction - PFC Enhanced High Power Factor Preregulator
