| Model Number | GTLP18T612MTD |
Product Details
The GTLP18T612 is an 18-bit universal bus transceiver which provides LVTTL to GTLP signal level translation. It allows for transparent, latched and clocked modes of data transfer. The device provides a high speed interface for cards operating at LVTTL logic levels and a backplane operating at GTLP logic levels. High speed backplane operation is a direct result of GTLP’s reduced output swing (< 1V), reduced input threshold levels and output edge rate control. The edge rate control minimizes bus settling time. GTLP is a Fairchild Semiconductor derivative of the Gunning Transistor logic (GTL) JEDEC standard JESD8-3.
■ Bidirectional interface between GTLP and LVTTL logic levels
■ Edge Rate Control to minimize noise on the GTLP port
■ Power up/down high impedance for live insertion
■ External VREF pin for receiver threshold
■ BiCMOS technology for low power dissipation
■ Bushold data inputs on A Port eliminates the need for external pull-up resistors for unused inputs
■ LVTTL compatible Driver and Control inputs
■ Flow-through architecture optimizes PCB layout
■ Open drain on GTLP to support wired-or connection
■ A-Port source/sink −24 mA/+24 mA
■ B-Port sink capability +50 mA
■ D-type flip-flop, latch and transparent data paths
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | onsemi |
| Product Category | Universal Bus Functions |
| Series | 74GTLP |
| Packaging | Tube |
| Package-Case | 56-TFSOP (0.240", 6.10mm Width) |
| Operating-Temperature | -40°C ~ 85°C |
| Mounting-Type | Surface Mount |
| Voltage-Supply | 3.15 V ~ 3.45 V |
| Supplier-Device-Package | 56-TSSOP |
| Number-of-Circuits | 18-Bit |
| Number-of-Inputs | - |
| Current-Output-High-Low | 24mA, 24mA |
| Logic-Type | Universal Bus Transceiver |
