AT91SAM9G45-CU Microprocessors MPU 64K SRAM 64K ROM 400MHz DDR2

                                                                  AT91SAM9G45-CU Datasheet

Product Details

Description

The ARM926EJ-S based AT91SAM9G45 features the frequently demanded combination of user interface functionality and high data rate connectivity, including LCD Controller, resistive touchscreen, camera interface, audio, Ethernet 10/100 and high speed USB and SDIO. With the processor running at 400MHz and multiple 100+ Mbps data rate peripherals, the AT91SAM9G45 has the performance and bandwidth to the network or local storage media to provide an adequate user experience.

Features

• 400 MHz ARM926EJ-S™ ARM® Thumb® Processor
– 32 KBytes Data Cache, 32 KBytes Instruction Cache, MMU
• Memories
– DDR2 Controller 4-bank DDR2/LPDDR, SDRAM/LPSDR
– External Bus Interface supporting 4-bank DDR2/LPDDR, SDRAM/LPSDR, Static Memories, CompactFlash, SLC NAND Flash with ECC
– One 64-KByte internal SRAM, single-cycle access at system speed or processor speed through TCM interface
– One 64-KByte internal ROM, embedding bootstrap routine
• Peripherals
– LCD Controller supporting STN and TFT displays up to 1280*860
– ITU-R BT. 601/656 Image Sensor Interface
– USB Device High Speed, USB Host High Speed and USB Host Full Speed with OnChip Transceiver
– 10/100 Mbps Ethernet MAC Controller
– Two High Speed Memory Card Hosts (SDIO, SDCard, MMC)
– AC97 controller
– Two Master/Slave Serial Peripheral Interfaces
– Two Three-channel 32-bit Timer/Counters
– Two Synchronous Serial Controllers (I2S mode)
– Four-channel 16-bit PWM Controller
– Two Two-wire Interfaces
– Four USARTs with ISO7816, IrDA, Manchester and SPI modes
– 8-channel 10-bit ADC with 4-wire Touch Screen support
• System
– 133 MHz twelve 32-bit layer AHB Bus Matrix
– 37 DMA Channels
– Boot from NAND Flash, SDCard, DataFlash® or serial DataFlash
– Reset Controller with on-chip Power-on Reset
– Selectable 32768 Hz Low-power and 12 MHz Crystal Oscillators
– Internal Low-power 32 kHz RC Oscillator
– One PLL for the system and one 480 MHz PLL optimized for USB High Speed
– Two Programmable External Clock Signals
– Advanced Interrupt Controller and Debug Unit
– Periodic Interval Timer, Watchdog Timer, Real Time Timer and Real Time Clock
• I/O
– Five 32-bit Parallel Input/Output Controllers
– 160 Programmable I/O Lines Multiplexed with up to Two Peripheral I/Os with Schmitt trigger input
• Package
– 324-ball TFBGA, pitch 0.8 mm
