STM32F100VCT6B ARM Microcontrollers - MCU ARM 32Bit Value Line 100-Pin 32kB Flash

                                                                  STM32F100VCT6B Datasheet

Product Details

Description

The STM32F100xx value line family incorporates the high-performance ARM Cortex™-M3 32-bit RISC core operating at a 24 MHz frequency, high-speed embedded memories (Flash memory up to 512 Kbytes and SRAM up to 32 Kbytes), a flexible static memory control (FSMC) interface (for devices offered in packages of 100 pins and more) and an extensive range of enhanced peripherals and I/Os connected to two APB buses. All devices offer standard communication interfaces (up to two I2Cs, three SPIs, one HDMI CEC, up to three USARTs and 2 UARTS), one 12-bit ADC, two 12-bit DACs, up to 9 general-purpose 16-bit timers and an advanced-control PWM timer.
The STM32F100xx high-density value line family operates in the –40 to +85 °C and –40 to +105 °C temperature ranges, from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving mode allows the design of low-power applications.
The STM32F100xx value line family includes devices in three different packages ranging from 64 pins to 144 pins. Depending on the device chosen, different sets of peripherals are included, the description below gives an overview of the complete range of peripherals proposed in this family.
These features make the STM32F100xx value line microcontroller family suitable for a wide range of applications such as motor drives, application control, medical and handheld equipment, PC and gaming peripherals, GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVACs.

Features

■ Core: ARM 32-bit Cortex™-M3 CPU
– 24 MHz maximum frequency, 1.25 DMIPS /MHz (Dhrystone 2.1) performance
– Single-cycle multiplication and hardware division
■ Memories
– 256 to 512 Kbytes of Flash memory
– 24 to 32 Kbytes of SRAM
– Flexible static memory controller with 4 Chip Selects. Supports SRAM, PSRAM and NOR memories
– LCD parallel interface, 8080/6800 modes
■ Clock, reset and supply management
– 2.0 to 3.6 V application supply and I/Os
– POR, PDR and programmable voltage detector (PVD)
– 4-to-24 MHz crystal oscillator
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC
– PLL for CPU clock
– 32 kHz oscillator for RTC with calibration
■ Low power
– Sleep, Stop and Standby modes
– VBAT supply for RTC and backup registers
■ Serial wire debug (SWD) and JTAG I/F
■ DMA
– 12-channel DMA controller
– Peripherals supported: timers, ADC, SPIs, I2Cs, USARTs and DACs
■ 1 × 12-bit, 1.2 µs A/D converter (up to 16 ch.)
– Conversion range: 0 to 3.6 V
– Temperature sensor
■ 2 × 12-bit D/A converters
■ Up to 112 fast I/O ports
– 51/80/112 I/Os, all mappable on 16 external interrupt vectors and almost all 5 V-tolerant
■ Up to 16 timers
– Up to seven 16-bit timers, each with up to 4 IC/OC/PWM or pulse counter
– One 16-bit, 6-channel advanced-control timer: up to 6 channels for PWM output, dead time generation and emergency stop
– One 16-bit timer, with 2 IC/OC, 1 OCN/PWM, dead-time generation and emergency stop
– Two 16-bit timers, each with IC/OC/OCN/PWM, dead-time generation and emergency stop
– Two watchdog timers
– SysTick timer: 24-bit downcounter
– Two 16-bit basic timers to drive the DAC
■ Up to 11 communications interfaces
– Up to two I2C interfaces (SMBus/PMBus)
– Up to 3 USARTs (ISO 7816 interface, LIN, IrDA capability, modem control)
– Up to 2 UARTs
– Up to 3 SPIs (12 Mbit/s)
– Consumer electronics control (CEC) I/F
■ CRC calculation unit, 96-bit unique ID

Specifications

High-density value line, advanced ARM-based 32-bit MCU with 512 KB Flash, 16 timers, ADC, DAC & 11 comm interfaces

Features

Core: ARM 32-bit CortexTM-M3 CPU - 24 MHz maximum frequency, 1.25 DMIPS /MHz (Dhrystone 2.1) performance - Single-cycle multiplication and hardware division Memories to 512 Kbytes of Flash memory to 32 Kbytes of SRAM - Flexible static memory controller with 4 Chip Selects. Supports SRAM, PSRAM and NOR memories - LCD parallel interface, 8080/6800 modes Clock, reset and supply management 3.6 V application supply and I/Os - POR, PDR and programmable voltage detector (PVD) - 4-to-24 MHz crystal oscillator - Internal 8 MHz factory-trimmed RC - Internal 40 kHz RC - PLL for CPU clock - 32 kHz oscillator for RTC with calibration Low power - Sleep, Stop and Standby modes - VBAT supply for RTC and backup registers Serial wire debug (SWD) and JTAG I/F DMA - 12-channel DMA controller - Peripherals supported: timers, ADC, SPIs, I2Cs, USARTs and DACs 1.2 μs A/D converter (up to 16 ch.) - Conversion range: V - Temperature sensor × 12-bit D/A converters to 112 fast I/O ports - 51/80/112 I/Os, all mappable on 16 external interrupt vectors and almost all 5 V-tolerant

to 16 timers Up to seven 16-bit timers, each with to 4 IC/OC/PWM or pulse counter - One 16-bit, 6-channel advanced-control timer: to 6 channels for PWM output, dead time generation and emergency stop - One 16-bit timer, with 2 IC/OC, 1 OCN/PWM, dead-time generation and emergency stop - Two 16-bit timers, each with IC/OC/OCN/PWM, dead-time generation and emergency stop - Two watchdog timers - SysTick timer: 24-bit downcounter - Two 16-bit basic timers to drive the DAC to 11 communications interfaces Up to two I2C interfaces (SMBus/PMBus) to 3 USARTs (ISO 7816 interface, LIN, IrDA capability, modem control) to 2 UARTs to 3 SPIs (12 Mbit/s) - Consumer electronics control (CEC) I/F CRC calculation unit, 96-bit unique ID Device summary

ARMR CortexTM-M3 core with embedded Flash and SRAM. 13 Embedded Flash memory. 13 CRC (cyclic redundancy check) calculation unit. 13 Embedded SRAM. 13 FSMC (flexible static memory controller). 13 LCD parallel interface. 13 Nested vectored interrupt controller (NVIC). 14 External interrupt/event controller (EXTI). 14 Clocks and startup. 14 Boot modes. 14 Power supply schemes. 15 Power supply supervisor. 15 Voltage regulator. 15 Low-power modes. 15 DMA. 16 RTC (real-time clock) and backup registers. 16 Timers and watchdogs. 16 I2C bus. 19 Universal synchronous/asynchronous receiver transmitter (USART). 19 Universal asynchronous receiver transmitter (UART). 19 Serial peripheral interface (SPI). 20 GPIOs (general-purpose inputs/outputs). 20 Remap capability. 20 ADC (analog-to-digital converter). 20 DAC (digital-to-analog converter). 21 Temperature sensor. 21 Serial wire JTAG debug port (SWJ-DP). 21

Minimum and maximum values. 34 Typical values. 34 Typical curves. 34 Loading capacitor. 34 Pin input voltage. 34 Power supply scheme. 35 Current consumption measurement. 36

General operating conditions. 37 Operating conditions at power-up / power-down. 38 Embedded reset and power control block characteristics. 39 Embedded reference voltage. 40 Supply current characteristics. 40 External clock source characteristics. 47 Internal clock source characteristics. 52 PLL characteristics. 53 Memory characteristics. 54 FSMC characteristics. 54 EMC characteristics. 66 Absolute maximum ratings (electrical sensitivity). 67 I/O current injection characteristics. 68 I/O port characteristics. 69 NRST pin characteristics. 74 TIMx characteristics. 75 Communications interfaces. 75 12-bit ADC characteristics. 80 DAC electrical specifications. 85 Temperature sensor characteristics. 87
