| Place of Origin | Call |
| Brand Name | Xilinx |
| Certification | ROHS |
| Model Number | XCZU19EG-2FFVC1760E |
Product Details
Dual Input Low Dropout Voltage Regulator
The PJ1581/PJ1582/PJ1583 family is a positive adjustable and fixed voltage regulator developed to provide 5A, 3A, 1.5A with Higher efficiency than currently available devices. All internal circuit is designed to operate down to 700mV input to output differential and the dropout voltage is fully specified as a function of load current. Dropout voltage of the device is 100mV at light loads and rising to 700mV at maximum output current. A Second low current input is required to achieve this dropout. The PJ1581/PJ1582/PJ1583 family is designed to prevent device failure under the worst operation condition with both Thermal Shutdown and Current Fold-back.
● Very low dropout voltage: 700mV at output current
● Low current Consumption
● High Accuracy Output Voltage: +/- 1%
● Thermal Shutdown
● Current Limiting
● Fast transient response
● Remote sense
● High efficiency linear voltage regulators
● Post regulators for switching supplies.
● Adjustable power supply
● Advance graphic card
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Xilinx |
| Product Category | IC Chips |
| Categories | Embedded - System On Chip (SoC) |
| Manufacturer | Xilinx Inc. |
| Series | Zynq? UltraScale+? MPSoC EG |
| Packaging | Tray |
| Part-Status | Active |
| Architecture | MCU, FPGA |
| Core-Processor | Quad ARM? Cortex?-A53 MPCore? with CoreSight?, Dual ARM?Cortex?-R5 with CoreSight? |
| MCU-Flash | - |
| MCU-RAM | 256KB |
| Peripherals | DMA, WDT |
| Connectivity | CAN, EBI/EMI, Ethernet, I?C, MMC/SD/SDIO, SPI, UART/USART, USB OTG |
| Speed | 600MHz, 1.5GHz |
| Primary-Attributes | Zynq?UltraScale+? FPGA, 1143K+ Logic Cells |
| Operating-Temperature | 0°C ~ 100°C (TJ) |
| Package-Case | 1760-BBGA, FCBGA |
| Supplier-Device-Package | 1760-FCBGA (42.5x42.5) |
| Number-of-I-O | 512 I/O |
Descriptions
Quad ARM? Cortex?-A53 MPCore? with CoreSight?, Dual ARM?Cortex?-R5 with CoreSight? System On Chip (SOC) IC Zynq? UltraScale+? MPSoC EG Zynq?UltraScale+? FPGA, 1143K+ Logic Cells 256KB 600MHz, 1.5GHz 1760-FCBGA (42.5x42.5)
