| Place of Origin | Call |
| Brand Name | Freescale / NXP |
| Certification | ROHS |
| Model Number | MC7448THX1267ND |
Product Details
the HMc744lc3 is a 1:2 Fanout Buffer designed to support data transmission rates up to 14 gbps, and clock frequencies as high as 14 gHz.
inputs terminated internally to 50 ohms
differential & Single-ended operation
propagation delay: 120 ps
Fast Rise and Fall times: 22 / 20 ps
programmable differential
output Voltage Swing: 600 - 1100 mV
low power consumption: 287 mW typ.
Single Supply: +3.3 V
16 lead ceramic 3x3 mm SMt package: 9 mm2
the HMc744lc3 is ideal for:
• RF ATE Applications
• Broadband Test & Measurement
• Serial Data Transmission up to 14 Gbps
• Clock Buffering up to 14 GHz
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Freescale / NXP |
| Product Category | Microprocessors |
| Series | MPC74xx |
| Packaging | Tray |
| Unit-Weight | 0.094136 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 360-BCBGA, FCCBGA |
| Operating-Temperature | -40°C ~ 105°C (TA) |
| Supplier-Device-Package | 360-FCCBGA (25x25) |
| Memory-Type | L1/L2 Cache |
| I/O Voltage | 1.5V, 1.8V, 2.5V |
| Speed | 1.267GHz |
| Core-Processor | PowerPC G4 |
| Bus width | 1 Core, 32-Bit |
| Co-Processors-DSP | Multimedia; SIMD |
| RAM-Controllers | - |
| Graphics-Acceleration | No |
| Display-&-Interface-Controllers | - |
| Ethernet | - |
| SATA | - |
| USB | - |
| Security-Features | - |
| Bus width | 1 Core |
| Maximum Operating Temperature | + 105 C |
| Operating temperature range | 0 C |
| Operating-Supply-Voltage | 1.05 V |
| Core | e600 |
| Processor-Series | MPC7448 |
| Data-Bus-Width | 32 bit |
| Package-Case | HCTE-BGA-360 |
| Maximum-Clock-Frequency | 1.267 GHz |
| L1-Cache-Instruction-Memory | 32 kB |
| L1-Cache-Data-Memory | 32 kB |
| I-O-Voltage | 1.5 V 1.8 V 2.5 V |
| Instruction-Type | Floating Point |
| L2-Cache-Instruction-Data-Memory | 1 MB |
| Number-of-Timers-Counters | - |
| Watchdog-Timers | No Watchdog Timer |
| Mfr | NXP USA Inc． |
| Package | Tray |
| Product-Status | Last Time Buy |
| Number-of-Cores-Bus-Width | 1 Core 32-Bit |
| Voltage-I-O | 1．5V 1．8V 2．5V |
| Package-Case | 360-BCBGA FCCBGA |
| Additional-Interfaces | - |
| Base-Product-Number | MC7448THX126 |
