| Place of Origin | Call |
| Brand Name | NXP Semiconductors |
| Certification | ROHS |
| Model Number | S9S12G128AMLH |
Product Details
The MC9S12HY/HA family is an automotive, 16-bit microcontroller product line that is specifically designed for entry level instrument clusters. This family also services generic automotive applications requiring CAN, LCD, Motor driver control or LIN/J2602. Typical examples of these applications include instrument clusters for automobiles and 2 or 3 wheelers, HVAC displays, general purpose motor control and body controllers.
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NXP Semiconductors |
| Product Category | Microcontrollers |
| Series | HCS12 |
| Packaging | Tray |
| Mounting-Style | SMD/SMT |
| Package-Case | LQFP-64 |
| Operating-Temperature | -40°C ~ 125°C (TA) |
| Number-of-I-O | 54 I/O |
| Speed | 25MHz |
| EEPROM-Size | 4K x 8 |
| Core-Processor | 12V1 |
| RAM-Size | 8K x 8 |
| Program Memory | FLASH |
| Peripherals | LVD, POR, PWM, WDT |
| Connectivity | CANbus, IrDA, LINbus, SCI, SPI |
| Voltage-Supply-Vcc-Vdd | 3.13V ~ 5.5V |
| Core-Size | 16-Bit |
| Program-Memory-Size | 128KB (128K x 8) |
| Data-Converters | A/D 12x10b |
| Oscillator-Type | Internal |
| Product-Type | 16-bit Microcontrollers - MCU |
| Factory-Pack-Quantity | 800 |
