| Model Number | 9LPR501SGLFT |
Product Details
ICS9LPRS525 is compliant Intel CK505 Yellow Cover specification. This clock synthesizer provides a single chip solution for Intel desktop chipsets. ICS9LPRS525 is driven with a 14.318MHz crystal. It also provides a tight ppm accuracy output for Serial ATA and PCI-Express support.
• Supports spread spectrum modulation, 0 to -0.5% down spread
• Supports CPU clks up to 400MHz
• Uses external 14.318MHz crystal, external crystal load
caps are required for frequency tuning
• 2 - CPU differential low power push-pull pairs
• 7 - SRC differential push-pull pairs
• 1 - CPU/SRC selectable differential low power push-pull pair
• 1 - SRC/DOT selectable differential low power push-pull pair
• 1 - SRC/SE selectable differential push-pull pair/Single-ended outputs
• 5 - PCI, 33MHz
• 1 - USB, 48MHz
• 1 - REF, 14.318MHz
56-pin CK505 compatible clock, w/fully integrated Vreg and series
resistors on differential outputs
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Integrated Circuit Systems |
| Product Category | Application-Specific Clock/Timing ICs |
| Series | 9LPR501 |
| Packaging | Tape & Reel (TR) Alternate Packaging |
| Unit-Weight | 0.009263 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 64-TFSOP (0.240", 6.10mm Width) |
| Operating-Temperature | 0°C ~ 70°C |
| Mounting-Type | Surface Mount |
| Voltage-Supply | 3.135 V ~ 3.465 V |
| Supplier-Device-Package | 64-TSSOP |
| PLL | Yes |
| Main-Purpose | Intel CK505, PCI Express (PCIe) |
| Input | Crystal |
| Output | Clock |
| Number-of-Circuits | |
| Ratio of output to input | |
| Differential-Input:Output | No/Yes |
| Frequency-Max | 400MHz |
| Part-#-Aliases | 9LPR501 ICS9LPR501SGLFT |
| Package-Case | TSSOP-64 |
