| Place of Origin | Call |
| Brand Name | STMicroelectronics |
| Certification | ROHS |
| Model Number | BZW50-47B |
Product Details
Transil diodes provide high overvoltage protection by clamping action. Their instantaneous response to transient overvoltages makes them particularly suited to protect voltage sensitive devices such as MOS Technology and low voltage supplied ICs.
■ Peak pulse power: 5000 W (10/1000 µs)
■ Stand-off voltage range from 10 V to 180 V
■ Unidirectional and bidirectional types
■ Low clamping factor
■ Fast response time
■ UL497B, file number: QVGQ2.E136224
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | TVS Diodes |
| Series | BZW50, TRANSIL™ |
| Type | Zener |
| Packaging | Cut Tape (CT) Alternate Packaging |
| Unit-Weight | 0.072241 oz |
| Mounting-Style | Through Hole |
| Termination-Style | Axial |
| Tradename | Transil |
| Operating-Temperature-Range | - 65 C to + 175 C |
| Length | 9.1 mm |
| Width | 9.1 mm |
| Package-Case | R6, Axial |
| Operating-Temperature | - |
| Mounting-Type | Through Hole |
| Applications | General Purpose |
| Supplier-Device-Package | R-6 |
| Diameter | 9.1 mm |
| Unidirectional-Channels | |
| Bidirectional-Channels | 1 |
| Voltage-Reverse-Standoff-Typ | 47V |
| Breakdown Voltage | 52V |
| Clamping Voltage | 108V |
| Current-Peak-Pulse-10-1000μs | 556A (8/20μs) |
| Power-Peak-Pulse | 5000W (5kW) |
| Power-Line-Protection | No |
| Capacitance-Frequency | 2050pF @ 1MHz |
| Pd-Power-Dissipation | 5 kW |
| Maximum Operating Temperature | + 175 C |
| Operating temperature range | - 65 C |
| Breakdown-Voltage | 52 V |
| Clamping-Voltage | 83.2 V |
| Peak-Surge-Current | 556 A |
| Working-Voltage | 47 V |
| Polarity | Unidirectional |
