ACPL-796J-500E Optically Isolated Amplifiers 5MHz-20MHz,5000 Amplifier ICs Vrms Sigma-Delta Modulatr

                                                                            ACPL-796J-500E Datasheet

Product Details

Description

The ACPL-796J is a 1-bit, second-order sigma-delta (Σ-Δ) modulator converts an analog input signal into a high-speed data stream with galvanic isolation based on optical coupling technology. The ACPL-796J operates from a 5 V power supply with dynamic range of 80 dB with an appropriate digital filter. The differential inputs of ±200 mV (full scale ±320 mV) are ideal for direct connection to shunt resistors or other low-level signal sources in applications such as motor phase current measurement.

Features

• 5 MHz to 20 MHz external clock input range
• 1-bit, second-order sigma-delta modulator
• 16 bits resolution no missing codes (12 bits ENOB)
• 74 dB minimum SNR
• 3.5 μV/°C maximum offset drift
• ±1% maximum gain error
• Internal reference voltage
• ±200 mV linear range with single 5 V supply
• 3 V to 5.5 V wide supply range for digital interface
• –40°C to +105°C operating temperature range
• SO-16 package
• 25 kV/μs common-mode transient immunity
• Safety and regulatory approval:
IEC/EN/DIN EN 60747-5-5: 1414 Vpeak working
insulation voltage
UL 1577: 5000 Vrms/1min double protection rating
CSA: Component Acceptance Notice #5

Applications

• Motor phase and rail current sensing
• Power inverter current and voltage sensing
• Industrial process control
• Data acquisition systems
• General purpose current and voltage sensing
• Traditional current transducer replacements
