| Place of Origin | Call |
| Brand Name | NXP |
| Certification | ROHS |
| Model Number | MPC8313CVRAFFC |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Freescale / NXP |
| Product Category | Microprocessors |
| Series | MPC83xx |
| Packaging | Tray |
| Unit-Weight | 0.193897 oz |
| Mounting-Style | SMD/SMT |
| Tradename | PowerQUICC |
| Package-Case | 516-BBGA Exposed Pad |
| Operating-Temperature | -40°C ~ 105°C (TA) |
| Supplier-Device-Package | 516-TEPBGA (27x27) |
| Memory-Type | L1 Cache |
| I/O Voltage | 1.8V, 2.5V, 3.3V |
| Speed | 333MHz |
| Core-Processor | PowerPC e300c3 |
| Bus width | 1 Core, 32-Bit |
| Co-Processors-DSP | - |
| RAM-Controllers | DDR, DDR2 |
| Graphics-Acceleration | No |
| Display-&-Interface-Controllers | - |
| Ethernet | 10/100/1000 Mbps (2) |
| SATA | - |
| USB | USB 2.0 + PHY (1) |
| Security-Features | - |
| Bus width | 1 Core |
| Maximum Operating Temperature | + 105 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Voltage | 1 V |
| Interface-Type | Ethernet I2C PCIe SPI UART USB |
| Core | e300c3 |
| Processor-Series | PowerQUICC II Pro |
| Data-Bus-Width | 32 bit |
| Package-Case | PBGA-516 |
| Maximum-Clock-Frequency | 333 MHz |
| L1-Cache-Instruction-Memory | 16 kB |
| L1-Cache-Data-Memory | 16 kB |
| I-O-Voltage | 1.8 V 2.5 V 3.3 V |
| Instruction-Type | Floating Point |
| Number-of-Timers-Counters | 2 x 32 bit |
| Watchdog-Timers | Watchdog Timer |
