Semiconductor ICs
>
|
| Place of Origin | Call |
| Brand Name | Bourns |
| Certification | ROHS |
| Model Number | CDSOT23-SM712 |
This evaluation board serves as an aid in evaluating circuit protection on RS-485 serial device port solutions using Bourns® TBU® High-Speed Protector (HSP), MOV and TVS products to meet the required industry standards on RS-485 port interfaces. The recommended Bourns® TBU® HSP solution offers enhanced performance features over competing technologies, which can help the design engineer to increase the surge & transient protection level on RS-485 ports and place the entire circuit protection solution into a smaller PCB area. Bourns has developed a RS-485 evaluation board (measuring 50 mm x 25 mm x 1.2 mm) manufactured using FR4 PCB with nickel gold plating on top and bottom sides.
RoHS compliant*
Working peak voltage 7 V or 12 V
ESD protection 30 kV max.
Surge protection
Wireless systems
Network protection
Portable electronics
RS-485 port protection
| Attribute | Attribute Value |
|---|---|
| Manufacturer | BOURNS |
| Product Category | TVS Diodes |
| Series | CDSOT23-SM712 |
| Type | Zener |
| Packaging | Alternate Packaging |
| Part-Aliases | CDS0T23-SM712 |
| Mounting-Style | SMD/SMT |
| Termination-Style | SMD/SMT |
| Height | 1.11 mm |
| Length | 3.04 (Max) mm |
| Width | 1.4 (Max) mm |
| Package-Case | TO-236-3, SC-59, SOT-23-3 |
| Operating-Temperature | -55°C ~ 150°C (TJ) |
| Mounting-Type | Surface Mount |
| Applications | General Purpose |
| Number-of-Channels | 2 Channel |
| Supplier-Device-Package | SOT-23-3 |
| Unidirectional-Channels | - |
| Bidirectional-Channels | 2 |
| Voltage-Reverse-Standoff-Typ | 7V (Max), 12V (Max) |
| Breakdown Voltage | 7.5V, 13.3V |
| Clamping Voltage | 14V, 26V |
| Current-Peak-Pulse-10-1000μs | 17A (8/20μs) |
| Power-Peak-Pulse | 400W |
| Power-Line-Protection | No |
| Capacitance-Frequency | 75pF @ 1MHz |
| Pd-Power-Dissipation | 600 W |
| Maximum Operating Temperature | + 150 C |
| Operating temperature range | - 55 C |
| Breakdown-Voltage | 13.3 V |
| Clamping-Voltage | 19 V |
| Peak-Surge-Current | 30 A |
| Cd-Diode-Capacitance | 75 pF |
| Working-Voltage | 12 V |
| Polarity | Bidirectional |
