| Plaats van herkomst | Vraag |
| Merknaam | NXP |
| Certificering | ROHS |
| Modelnummer | SAF7772EL/200Z100Y |
Product Details
The AK4480 is a 32-bit DAC, which corresponds to Blu-ray Disc systems.An internal circuit includes newly developed 32bit Digital Filter for better sound quality achieving low distortion characteristics and wide dynamic range. The AK4480 has full differential SCF outputs, removing the need for AC coupling capacitors and increasing performance for systems with excessive clock jitter. The AK4480 accepts 216kHz PCM data and 1-bit DSD data, ideal for a wide range of applications including Blu-ray Discs and SACDs.
•128x Over Sampling
•Sampling Rate: 30kHz ∼216kHz
•32Bit 8x Digital Filter
- Ripple: ±0.005dB, Attenuation: 70dB
- Minimum delay option GD=7/fs
- Sharp Roll-off Filter
- Slow Roll-off Filter
•High Tolerance to Clock Jitter
•Low Distortion Differential Output
•DSD Data Input
•Digital De-emphasis for 32, 44.1, 48kHz Sampling
•Soft Mute
•Digital Attenuator (Linear 256 steps)
•Mono Mode
•External Digital Filter Mode
•THD+N: -100dB
•DR, S/N: 114dB (117dB when Mono mode)
•I/F Format: 24/32bit MSB justified,16/20/24/32bit LSB justified, I2S, DSD
• Master Clock:
30kHz ~ 32kHz: 1152fs
30kHz ~ 54kHz: 512fs or 768fs
30kHz ~ 108kHz: 256fs or 384fs
108kHz ~ 216kHz: 128fs or 192fs
•Power Supply: 4.75 ∼5.25V
•Digital Input Level: TTL
•Package: 30pin VSOP
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | |
| Product Category | IC Chips |
Descriptions
Who we are?
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer OF Integrated Circuit Chip . We can do OEM/ODM business.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: How to buy your products?
A: You can buy the products from our company directly.Normally the procedure is sign the contract, payment by T/T,Contact the shipping company to delivery the goods to your country.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
6-TSSOP,
